! Before operating your new appliance please read

this instruction booklet carefully. It contains

important information concerning the safe installation

and operation of the appliance.

! Please keep these operating instructions for future

reference. Make sure that the instructions are kept

with the appliance if it is sold, given away or moved.

! The appliance must be installed by a qualified

professional according to the instructions provided.

! Any necessary adjustment or maintenance must be

performed after the cooker has been disconnected

from the electricity supply.

Levelling

If it is necessary to level the

appliance, screw the

adjustable feet into the places

provided on each corner of the

base of the cooker (see figure).

The legs* fit into the slots on

the underside of the base of

the cooker.

Electrical connection

Install a standardised plug corresponding to the

load indicated on the appliance data plate (see

Technical data table).

The appliance must be directly connected to the mains

using an omnipolar circuit-breaker with a minimum

contact opening of 3 mm installed between the

appliance and the mains. The circuit-breaker must be

suitable for the charge indicated and must comply with

NFC 15-100 regulations (the earthing wire must not be

interrupted by the circuit-breaker). The supply cable

must be positioned so that it does not come into

contact with temperatures higher than 50°C at any point.

Before connecting the appliance to the power

supply, make sure that:

 The appliance is earthed and the plug is compliant

with the law.

 The socket can withstand the maximum power of

the appliance, which is indicated by the data plate.

 The voltage is in the range between the values

indicated on the data plate.

 The socket is compatible with the plug of the

appliance. If the socket is incompatible with the

plug, ask an authorised technician to replace it.

Do not use extension cords or multiple sockets.

! Once the appliance has been installed, the power

supply cable and the electrical socket must be

easily accessible.

! The cable must not be bent or compressed.

! The cable must be checked regularly and replaced

by authorised technicians only.

! The manufacturer declines any liability should

these safety measures not be observed.

Installation of the cooker

The appliance can be installed next to cabinets,

provided the height does not exceed that of the hob.

If the cooker is placed touching walls or sides of

neighbouring cabinets, these must be capable of

withstanding a temperature rise of 50°C above room

temperature. For a correct installation of the cooker

the following precautions must be followed:

 The furniture units next to the cooker, that is

higher than the working boards, must be placed

at least 600 mm from the edge of the board.

Curtains must not be fitted immediately behind

the cooker or within 600 mm. of the sides of the

cooker.

Connecting the gas

The appliance should be connected to a gas

cylinder in compliance with current directives. On

some models the gas supply can be connected on

the left or on the right, as necessary; to change the

connection, reverse the position of the hose holder

with that of the cap and replace replace the gasket

(supplied with the appliance). Remember to install a

pressure regulator on the LPG cylinder, which

complies with current directive.

! Check that the supply pressure complies with the

values indicated in table 1 Characteristics of the

burners and nozzles since this will ensure safe

operation, correct consumption and ensure a longer

life to your appliance.

Installation

* Only available in certain models
