1
IMPORTANT NOTES
Before operating the appliance, please read the instruction manual and follow the instructions provided. The
manufacturer is not liable for any damages resulting from use of the appliance contrary to its intended use or
inappropriate use. Keep the instruction manual for future reference.
The appliance is intended for home use only. Do not use for other purposes contrary to its intended use. Do not use
for medical or commercial purposes.
This appliance may be used by children of at least 8 years of age and by persons with reduced physical, mental
abilities and persons with no experience or knowledge of the equipment, if supervised or instructed on its safe use
so that the risks associated with it were understandable. Children should not play with the appliance nor clean or
carry out maintenance of the appliance unattended.
The scale is a precision device. Do not drop, hit or shake it.
If the scale is not used for a long time, remove the batteries. Batteries that are flat or out of use for a long time may
leak.
When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by
the European Directive 2012/19/EU. Please inform yourself about the local separate collection system for
electrical and electronic products. Used appliance should be delivered to the dedicated collecting points due
to hazardous components, which may affect the environment. Do not dispose this appliance in the common
waste bin.
Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be dispose with
normal household waste. Please inform yourself about the local rules on separate collection of batteries
because correct disposal helps to prevent negative consequences for the environmental and human health.
Device is compliant with EU directives:
- Electromagnetic compatibility (EMC)
Device marked CE mark on rating label
1. Buttons
2. Display
3. Triangular ring
4. Belt
5. Hook
USE OF THE DEVICE
Tie the belt through the luggage handle by hooking the hook onto the triangular ring. Make sure the belt is not loaded. Activate
the scale by pressing the on/off button and wait for the scale to calibrate by showing "0" on the display. Lift the scale by holding
it in a horizontal position. The display will show the result of the measurement and after three seconds it will be locked (it will
stop fluctuating and "H" will appear next to the scale). To start the scale press the on/off button after locking. The
display will show 0 and the indication "T". The scale will automatically switch off after 2 minutes of inactivity. To switch off the
scale manually hold down the on/off button for 3 seconds.
Change of units:
To change the units of measurement press the
Weight limit setting:
After starting the scale, hold down the button longer . Use the and buttons to select the expected weight
limit value. Save the setting by longer pressing the
button .
Error indications:
- The battery needs to be replaced.
- Weight overloaded.
Battery replacement:
Open the battery cover. Remove the used battery. Place new battery paying attention to polarity and battery markings.
TECHNICAL DATA
Load capacity: 50 kg, gradation 0.05 kg
Power supply: 1 x 3V (Cr2032)
LGS301/LGS501
Function buttons:
On/Off/Tare/Increase value
Change unit/set limit/decrease value
