4

CAUTION

SPIDER ALERT!

If your barbeque is getting hard to light or the flame is

weak, check and clean the venturis and burners.

Spiders or small insects are known to create “flashback”

problems by building nests and laying eggs in the

barbeque’s venturi or burner obstructing the flow of gas.

The backed-up gas can ignite behind the control panel.

This flashback can damage your barbeque and cause

injury. To prevent flashbacks and ensure good

performance, the burner and venturi tube assembly should

be removed and cleaned whenever the barbeque has been

idle for an extended period of time.

SPIDER AND WEBS

INSIDE BURNER

Make sure gas is turned on at cylinder.

Make sure there is gas in the cylinder.

Does the ignitor make a sparking noise?

If yes check for spark at burner.

If no spark check for damaged or loose wires.

If wires are OK check for cracked or broken electrode, replace if

needed.

If wire or electrodes are covered by cooking residue, clean

electrode tip with alcohol wipe if needed.

If needed replace wires.

If no sound check battery.

Make sure battery is installed correctly.

Check for loose wire connection at module and switch.

If ignitor continues to not work then use match.

IF APPLIANCE FAILS TO LIGHT

1. Turn all appliance control knobs to .

2. Be sure regulator is tightly connected to gas cylinder.

3. Turn on Gas. If you hear a rushing sound, turn gas off

immediately. There is a major leak at the connection.

Correct before proceeding.

4. Brush soapy solution (mixture of half soap and half water)

onto hose connections.

5. If growing bubbles appear, there is a leak. Turn off gas at

cylinder immediately and check tightness of connections. If

leak cannot be stopped do not try to repair. Call for

replacement parts.

6. Always turn off gas at cylinder after performing leak test.

Leak test before first use, at least once a year, and every time

the cylinder is changed or disconnected.

Leak Testing Valves, Hose and Regulator

TECHNICAL DATA

Appliance

Name

Total

Nominal

Gas

Category

I3B/P(30) I3B/P(50)

Model No. 468101015

Gas Type Butane Propane Butane, Propane or their mixtures Butane, Propane or their mixtures

Gas

Pressure

28-30 mbar 37 mbar 28-30 mbar 50 mbar

Grill: 0,91 x 3 pcs Grill: 0,81 x 3 pcs

Hotplate: 0,75 Hotplate: 0,64

Destination

of countries

DK, NO, NL, SE, Fl, RO, IS, CZ, IT AT, DE, SK, CH, LUGB, FR, IE, BE, ES, IT, PT, CZ

Char-Broil, LLC

Gas Barbeque/Gas Grill

12,8 kW (931g/h)

I3+(28-30/37)

Injector Size

(Dia. Mm)

Grill: 0,91 x 3 Pcs

Hotplate: 0,75

468201015, 468201015-C1, 468201015-C4

Environmental protection

Discarded electric appliances are recyclable

and should not be discarded in the domestic

waste! Please actively support us in

conserving resources and protecting the

environment by returning this appliance to the

collection centres (if available).
