INSTRUCTION MANUAL

INSTRUCTION

Please read this instruction carefully in order to use the scale correctly & keep the scale in good

condition.

FEATURES AND SPECIFICATIONS

1. Default real time clockindication when idle

2. Alarm timer setting, ambient temperature sensor/indication

3. Measuring uid volume vs weight for milk, water.

4. g (kg)/lb:oz convertible indication.

5. Low battery power (Lo)/Overload indication (Err)

6. Using high precision strain gauge sensor

7. Zero/Tarefunction

8. Two operation modes Mounting on wall or putting on platform

OUTLINE (see g. 1)

ACCESSORY

1. screw x 2

2. plastic anchor x 2

TO INSTALL THE SCALE (see g. 2)

1. The distance between 2 screws is 87.7mm

2. Find the position on wall where to mount the scale. Use a pencil to mark position of 2 nail

holes with 87.7mm distance.

3. Drill 2 nail holes on the marks.

4. Insert the 2 provided plastic anchors to the nail holes till they are jammed tight inside the nail

holes. Then drive 2 screws, one at a time, to the anchors into the wall. Ensure the screws

xed securely.

5. Now mount the scale by tting the 2 holes on the back side of scale to the 2 screws. Once

tted, pull the scale downwards to ensure the scale is well mounted. To dismantle, simply pull

the scale upwards.

LCD DISPLAY (see g. 3)

WORKING MODES

KEY ILLUSTATION

1. Alarm timer setting.

2. Down/Unit conversion

3. Switch

4. Up/Zero or tare

TO INSTALL BATTERY

1. Battery

2x3V lithium cells. Please remove isolation sheet before use.

2. To replace battery

A. Open battery case cover on the back of scale.

B. Bend the small contact outwards and the battery will come out.

C. Install new battery by putting one side of battery beneath the black tab and then pressing

down the other side until the battery is locked.

D. Close the battery case cover.

TO SET TIME (see g. 4)

1. Install battery and enter time setting mode automatically. When hour display is ashing,

press pq to set hour. Please mind AM/PM selection during setting.

2. Press „T-SET“ to conrm and prompt to minute setting. When minute display is ashing,

press pq to set minute.

3. Press „T-SET“ to nish time setting.

Remark:

1. Press „ON/OFFW to cancel time setting.

2. Return to real time display after idling for 60 seconds.

TO RE-SET TIME (see g. 5)

Under real time display mode, press „T-SET“ for 3 seconds to enter time setting mode.

TO CONVERT UNIT SYSTEMS

1. Applicable only when the scale is available in indication of Metric (g, kg) & Imperial (oz, Ib).

Press button ʻUnit‘ for 3 seconds, to convert between ʻg, kg‘ & ʻoz, Ib‘ indication anytime or

during course of weighing. (see g. 6)

2. Press button „Unit“ momentarily, to convert & cycle through measuring modes of : Weight-

Volume uid of water-Volume uid of milk. (see g. 7)

A = Metic system, B = Imperial system

Remark: The unit system of scale depends on sales destination or the requirement of

distributor.

TEMPERATURE SENSOR

1. Current temperature is shown at the higher right corner of LCD.

2. Temperature range: 0~+40°C

3. Division: 0.5°C

Note: Temperature indication in °C or °F is preset before ex-factory & can not change.

MODE CONVERSION (see g. 8)

OPERATION

Two operation modes: Mounting on wall or putting on platform

WEIGHING MODE (see g. 9)

1. When weighing platform is folded

2. Pull down the weighing platform to horizontal position. Scale will enter weighing mode

automatically.

3. Place weighing object on the glass platform. LCD will display the weight reading. If bowl is

used, put the bowl on the glass platform, and press Z/T button to reset LCD reading to „0“

before loading weighing object on the bowl. If the weighing object is water or milk, press

UNIT button to choose volume mode to view the volume of weighing object.

4. Fold the weighing platform or press ON/OFF button to exit weighing mode LCD will return to

displaying default real time clock.

ENGLISH

ENGLISH

N

i

1

2 3

4 5

6

7

8

1. LCD display

2. glass weighing platform

3. (folded)

4. (unfolded)

5. battery case cover

6. Holes

7. Bowl

8. (back view)

9. (side view)

1. Timer

2. Alarm

3. Tare

4. Negative Value

5. Zero

6. Room temperature

7. Temperature in °C or °F

8. AM real time clock display

9. Weight in Kg. or lb:oz

10. PM real time clock display

11. Water volume indicator

12. Milk volume indicator

13. Fluid volume

a

b

a

d

cb

M_6408_v02.indd 2-3 12-11-29 下午4:26
