Manual Hikoki DH 28PEC Ciocan rotopercutor

Manual

3

English

○ Do not attempt to use the rotary hammer in the rotation

and hammering function with the drill chuck and chuck

adapter attached. This would seriously shorten the

service life of every component of the machine.

12 RCD

The use of a residual current device with a rated residual

current of 30 mA or less at all times is recommended.

SYMBOLS

WARNING

The following show symbols used for the machine.

Be sure that you understand their meaning before

use.

DH28PEC: Rotary Hammer

To reduce the risk of injury, user must read

instruction manual.

Only for EU countries

Do not dispose of electric tools together with

household waste material!

In observance of European Directive 2012/19/

EU on waste electrical and electronic equipment

and its implementation in accordance with

national law, electric tools that have reached

the end of their life must be collected separately

and returned to an environmentally compatible

recycling facility.

V

Rated voltage

Ensure that the power source to be utilized

conforms to the power requirements specifi ed

on the product nameplate.

P

Power Input

n

0

No-load speed

Bpm Full-load impact rate

φ

max

Drilling diameter, max.

kg

Weight

(According to EPTA-Procedure 01/2003)

Concrete

Steel

Wood

Rotation and hammering function

Rotation only function

Hammering only function

Switching ON

Switching OFF

Changeover switch

Display lamp

Low mode

Normal mode

ROTARY HAMMER SAFETY

WARNINGS

1. Wear ear protectors

Exposure to noise can cause hearing loss.

2. Use auxiliary handle(s), if supplied with the tool.

Loss of control can cause personal injury.

3. Hold power tool by insulated gripping surfaces,

when performing an operation where the cutting

accessory may contact hidden wiring or its own

cord.

Cutting accessory contacting a “live” wire may make

exposed metal parts of the power tool “live” and could

give the operator an electric shock.

ADDITIONAL SAFETY WARNINGS

1. Ensure that the power source to be utilized conforms

to the power requirements specifi ed on the product

nameplate.

2. Ensure that the power switch is in the OFF position.

If the plug is connected to a receptacle while the power

switch is in the ON position, the power tool will start

operating immediately, which could cause a serious

accident.

3. When the work area is removed from the power source,

use an extension cord of suffi cient thickness and rated

capacity. The extension cord should be kept as short as

practicable.

4. Do not touch the bit during or immediately after

operation. The bit becomes very hot during operation

and could cause serious burns.

5. Before starting to break, chip or drill into a wall, fl oor or

ceiling, thoroughly confi rm that such items as electric

cables or conduits are not buried inside.

6. Always hold the body handle and side handle of the

power tool fi rmly. Otherwise the counterforce produced

may result in inaccurate and even dangerous operation.

7. Wear a dust mask

Do not inhale the harmful dusts generated in drilling or

chiseling operation. The dust can endanger the health of

yourself and bystanders.

8. Mounting the tool

○ To prevent accidents, make sure to turn the switch off

and disconnect the plug from the receptacle.

○ When using tools such as bull points, drill bits, etc.,

make sure to use the genuine parts designated by our

company.

○ Clean the shank portion of the tool.

○ Check the latching by pulling on the tool.

9. To prevent accidents, make sure to turn the switch off

and disconnect the plug from the receptacle when the

drill bits and other various parts are installed or removed.

The power switch should also be turned off during a work

break and after work.

10. Rotation + hammering

When the drill bit touches construction iron bar, the bit

will stop immediately and the rotary hammer will react to

revolve. Therefore fi rmly tighten the side handle.

11. Rotation only

To drill wood or metal material using the drill chuck and

chuck adapter (optional accessories).

○ Application of force more than necessary will not only

expedite the work, but will deteriorate the tip edge of the

drill bit and reduce the service life of the rotary hammer

in addition.

○ Drill bits may snap off while withdrawing the rotary

hammer from the drilled hole. For withdrawing, it is

important to use a pushing motion.

○ Do not attempt to drill anchor holes or holes in concrete

with the machine set in the rotation only function.

0000Book̲DH28PEC.indb30000Book̲DH28PEC.indb3 2019/01/2311:53:402019/01/2311:53:40
