TOUCH CONTROL PANEL

WASH CYCLE TABLE

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer (The detergent

dispenser drawer is located inside the machine and can be

accessed by opening the door)

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

DETERGENT DISPENSER DRAWER

Compartment 1: Pre-wash detergent (powder)

Compartment 2: Washing detergent (powder

or liquid)

If liquid detergent is used, the removable plastic

partition A (supplied) should be used for proper

dosage. If powder detergent is used, place the

partition into slot B.

Compartment : Additives (fabric softeners,

etc.)

We recommend that the maximum level

indicated by the grille is not exceeded, and that concentrated fabric

softeners are diluted.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

! To remove the drawer, press lever C and pull the drawer outwards.

1

2

180

210

150

120

90

60

B

A

C

1.

3.

2.

5.

7.

6.

8.

4.

GB

Quick Guide

THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.

To receive more comprehensive assistance, register the

appliance on www.hotpoint.eu/register

Prior to using the appliance, carefully read the Safety and installation instructions.

Prior to using the appliance, the bolts used for transport must be removed. For detailed

instructions on the removal procedure, consult the safety and installation instructions.

1. ON/OFF button with indicator light

2. WASH CYCLE SELECTOR knob

3. Buttons M1-M2

4. TEMPERATURE button

5. SPIN button

6. GREEN indicator light

7. START/PAUSE button with indicator light

8. WASH CYCLE PHASE icons

9. CONTROL PANEL LOCK indicator light

10. LOCK indicator light

11. DELAYED START button

12. OPTION buttons

13. DRYING button

TOUCH CONTROL PANEL

To adjust the settings, gently press the icon inside

the sensitive (touch control) area as illustrated in the

gure.

GREEN

1

2

3

DISPLAY

6 7 8

910

4 5

11

12

13

Max load 10 Kg

Power consumption in o -mode 0.5 W / in left-on mode 8 W

Detergents and

additives

Recommended

detergent

Residual

dampness % (***)

Energy

consumption kWh

Total water lt

Laundry

temperature °C

Programme

Temperatures

Max.

spin

speed

(rpm)

Max.

load for

washing

(kg)

Duration

(h : m)

Drying

Max.

load for

drying

(kg)

Prewash Wash

Fabric

softener

Powder Liquid

Setting Range 1 2

Drying Synthetics – – – – **



5.0 – – – – – – – – –

Eco 40-60 (1)

(Wash)

40 °C 40°C

1551 10.0 3:59



7.0

–

   

44 1.07 59 35

1551 5.0 3:00



–

   

44 0.83 59 35

1551 2.5 2:15



–

   

44 0.58 42 33

20°C 20 °C

- 20 °C

1600 10.0 1:50



7.0 –

 

–



54.5 0.20 95 22

Steam Refresh – – – 2.0 ** – – – – – – – – – – –

Cotton Hygiene Prewash

90°C

- 90°C

1600 10.0 3:10



7.0

    

54 1.90 100 70

Cotton (2)

40°C

- 60°C

1600 10.0 3:55



7.0 –

   

49 1.14 107 45

Synthetics Resistant (3) 40°C

- 60°C

1200 5.5 2:55



5.5

    

35 0.83 80

43

Whites

60°C

- 60°C

1600 10.0 **



7.0

    

– – – –

Coloureds 40°C

- 40°C

1600 10.0 **



7.0 –

 

–



– – – –

Wash&Dry 30°C 30°C 1600 1.0 **



1.0 –

 

–



– – – –

Wool 40°C

- 40°C

800 2.5 **



2.5 –

 

–



– – – –

Ultradelicates 30°C

- 30°C

600

(****)

1.0 **



1.0 –

 

–



– – – –

Rinse – – 1600 10.0 **



7.0 – –



– – – – – –

Spin + Pump out – – 1600 10.0 **



7.0 – – – – – – – –

Drying Cottons – – – – **



7.0 – – – – – – – – –

Drying Wool – – – – **



2.5 – – – – – – – – –

 Dosing required  Dosing optional

Eco 40-60 (4)

(Wash & Drying)

40 °C 40 °C

1551 7.0 9:50



7.0 –

   

0 5.10 75 33

1551 3.5 6:00



3.5 –

   

0 2.70 53 33

This data may dier in your home due to changing conditions in inlet water temperature, water

pressure etc. Approximate programme duration values refer to the default setting of the programmes,

without options.

The values given for programmes other than the Eco 40-60 programme are indicative

only.

Note: 10 minutes after the START, the machine will recalculate the time remaining until the end of the

wash cycle on the basis of the load inside it; this value will then be shown on the display.

1) (Wash)- Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The

most ecient programme in terms of energy and water consumption for washing normally soiled

cotton laundry.

Note: spin speed values shown on the display can slightly diers from the values stated in the

table.

4) (Wash & Drying)- Test wash and drying cycle in compliance with EU Ecodesign regulation

2019/20144

. To access “wash and dry” cycle select “Eco 40-60” wash programme and set option level

to

“Cupboard”.

The most ecient programme in terms of energy and water consumption for washing and

drying normally soiled cotton laundry. At the end of cycle the garments can be immediately stored to the

cupboard.

For all testing institutes:

2) Long cotton cycle: set cycle

at a temperature of 40°C.

3) Long synthetics cycle: set cycle at a temperature of 40°C.

** The duration of the wash cycles can be checked on the display.

*** After programme end and spinning with maximum selectable spin speed, in default programme

setting.

**** The display will show the suggested spin speed as default value.

! This symbol reminds you to read this instruction manual.
