Manual Indesit D2F HK26 S Maşină de spălat vase

Manual

ENQuick Guide

1

THANK YOU FOR BUYING AN INDESIT PRODUCT.

In order to receive a more complete assistance, please register

your appliance on: www.indesit.com/register

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that THE SALT RESERVOIR NEVER BE EMPTY.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher

(see PRODUCT DESCRIPTION) and must be lled when the SALT REFILL

indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Only the rst time you do this: ll the salt reservoir

with water.

3. Position the funnel (see gure) and ll the salt reservo-

ir right up to its edge (approximately 1 kg); it is not

unusual for a little water to leak out.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water so-

ftener beyond repair).

Whenever you need to add salt, it is mandatory to complete the

procedure before the beginning of the washing cycle to avoid corrosion.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse

aid dispenser A should be lled when when

the dark optical indicator on the dispenser

door C becomes transparent.

NEVER pour the rinse aid directly into the

appliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device D. Introduce the

detergent into the dry dispenser E only. Place the amount of detergent for

pre-washing directly inside the tub.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently

pre-

venting scale buildup on heater, contributing also to better cleaning

eciency.

This system regenerates itself with salt, therefore it is required to rell

salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

CONTROL PANEL

FIRST TIME USE

Before using the appliance carefully read Safety Instructions

guide.

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories:

For information on comparative EN testing conditions, please send an email to the following address: [email protected]

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

PROGRAMS TABLE

1. ON-OFF/Reset button with indicator light

2. Push & Go button with indicator light

3. Salt rell indicator light

4. Program selection knob

5. Delay indicator lights

6. Delay button with indicator light

7. START/Pause button with indicator light / Drain out

D

E

A

C

PLEASE SCAN THE QR CODE ON YOUR

APPLIANCE IN ORDER TO HAVE MORE

DETAILED INFORMATION

Program Programs description

Drying

phase

Avaiable

options

*)

Duration

of wash

program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

1.

Eco 50°- Eco program is suitable to clean normally soiled table-

ware, that for this use, it is the most ecient program in terms

of its combined energy and water consumption, and that it is

used to assess compliance with the EU Ecodesign legislation.

3:35 9.5 0.95

2.

Intensive 65° - Program recommended for heavily soiled

crockery, especially suitable for pans and saucepans (not to

be used for delicate items).

2:40 18.0 1.60

3.

Mixed 55° - Mixed soil. For normally soiled dishes with dried

food residues.

2:15 16.0 1.40

4.

Fast&Clean 28’

50° -

Program to be used for half load of

lightly-soiled dishes with no dried food residues. Does not

have drying phase.

-

0:28 9.0 0.50

5.

Pre-Wash

-

Use to refresh crockery planned to be washed

later. No detergent to be used with this program.

-

0:12 4.7 0.01

6.

Push&GO 50° - Everyday wash and dry cycle that ensures

great cleaning performance in a short time without the

need to pre-treat dishes.

- 1:30 11.5 1.30

1 2 3

4

6 7

5
