04 GB

2.3. ADAPTING THE HOB TO DIFFERENT

TYPES OF GAS

To adapt the Hob for use with different types of gas, carry out the

following instructions:

•Remove the grids and burners

•Insert on hexagonal spanner (7 mm) into the burner support

(Figure7)

•Unscrew the injector and replace it with one suitable for the gas to be

used (see gas type table)

2.4. REGULATING THE MINIMUM FLAME

After lighting the burners, turn the control knob to the minimum setting

and then remove the knob (this can easily be removed by applying

gentle pressure).

Using a small «Terminal» type screwdriver the regulating screw can

be adjusted as in Figure 9. Turning the screw clockwise reduces the

gas flow, whilst turning it anticlockwise increases the flow – Use this

adjustment to obtain a flame of approximately 3 to 4 mm in length and

then replace the control knob.

When the gas supply available is LPG - the screw to set the idle flame

must be turned (clockwise) to the end stop.

When you have carried out the new gas regulation, replace the old gas

rating plate on your appliance with one (supplied with hob) suitable for

the type of gas for which it has been regulated.

3. USE OF HOB - USER INSTRUCTIONS

This appliance must only be used for the purpose for which it is

intended, domestic cooking, and any other use will be considered

improper and could therefore be dangerous. The Manufacturer will

not be responsible for any damage or loss resulting from improper

use.

Before using burner, be sure, grid perimeters center the burner as

below figure.

If you are using Cast Iron Grids; underneath the grid, position of it is

stated. Be sure for the exact grid is used in correct position.

Table A

Burner Type

Ø pan/pot

(cm)

AUX

SR

R

10 - 18

12 - 22

16 - 26

Auxiliary

Semi Rapid

Rapid

Power

(kW)

1,00

1,75

2,70

G20 20 mbar

(methane)

95 l/h

167 l/h

257 l/h

G30 28-30 mbar

(LPG)

73 g/h

127 g/h

196 g/h

4. MAINTENANCE AND CLEANING

Before cleaning the hob, ensure the appliance has cooled down.

Remove the plug from the socket or (if connected directly) switch off

the electricity supply.

Cleaning and user maintenance shall not be made by children without

supervision

Never use abrasives, corrosive detergents, bleaching agents or

acids. Avoid any acid or alkaline substances (lemon, juice, vinegar

etc.) on the enamelled, varnished or stainless steel sections.

When cleaning the enamelled, varnished or chrome sections, use

warm soapy water or a non caustic detergent. For stainless steel use

an appropriate cleaning solution.

The burners can be cleaned with soapy water. To restore their original

shine, use a household stainless steel cleaner. After cleaning, dry the

burners and replace.

It is important the Burners are replaced correctly.

Chromed grids and burners

Chromed grids and burners have a tendency to discolour with use.

This does not jeopardize the functionality of the hob.

Our After Sales Service Centre can provide spare parts if required.

The gas burner should be regulated so that the flame does not overlap

the base of the pan. Vessels with a concave or convex base should not

be used.

WARNING: If a flame is accidentally extinguished, turn the knob

to the off position and do not attempt to re-ignite if for at least 1

minute.

If over the years the gas taps become stiff to turn it is necessary to

lubricate them.

Such operation must be carried out only by qualified Service

Engineers.

IMPORTANT: carry out a final check for leaks on the pipe

connections using a soapy solution. NEVER USE A FLAME.

Also, make sure that the flexible pipe cannot come into contact

with a moving part of the cabinet (eg.adrawer) and that it is not

situated where it could be damaged.

Warning: If gas can be smelt in the vicinity of this appliance turn off

the gas supply to the appliance and call the engineer directly. Do not

search for a leak with a naked flame.

3.1. USING THE GAS BURNER

Prior to switching on the gas hob ensure that the burners and burner

caps are correctly placed within their position.

This hob is fitted with electronic ignition to ignite the burner.

To ignite the burners carry out the following:

° push in and turn the knob anticlockwise to the larger flame symbol

and keep pushed 5 s after ignition.

The ignition system will continue to generate sparks as long as the

control knob is being pressed

Warning: If there is no electricity on appliance to ignite the burner a

match or a lighter should be used carring out the following:

°place a lighted match or lighter close to the burner

°push in and turn the knob anticlockwise to the larger flame symbol

and keep pushed 5 s after ignition.

Warning: In any case If after 5 s the burner has not lit, stop operating

the device and wait at least 1 min before attempting a further ignition

of the burner.

DC 4 kW Mono

16 - 26

4,00

381 l/h

291 g/h

DC 4,2 kW Mono

16 - 26

4,20 NG

4,00 LPG

400 l/h

291 g/h

DC 4,5 kW Mono

16 - 26

4,50

429 l/h

327 g/h

GENERAL ADVISE

For best results, use cooking vessels with a flat surface. The size of

the surface should match the gas burner side as follows. Table A.
