Manual Siemens VS08G2075 Aspirator

Manual

dede

Vacuuming with accessories

Figure

Pull the combination tool in the direction of

the arrow to remove it from the tool holder.

a)Crevice nozzle

For vacuuming in crevices and corners.

For difficult to reach places, the

combination tool can be extended to two

different lengths by pulling out the crevice

nozzle.



For either length extension, pull the crevice

nozzle out until you hear it engage.



The crevice nozzle can be pushed back in

again by releasing the telescopic locking

mechanism (pressing it in the direction of

the arrow).

b)Upholstery nozzle

For cleaning upholstered furniture,

curtains, etc.

c)Furniture brush

For window frames, cabinets, profiles etc.



Fold the upholstery nozzle over in the

direction of the arrow.



To extend the brush ring, turn in the

direction of the arrow.



Before replacing the combination tool

in the tool holder, retract the brush

ring and fold the upholstery nozzle

back.

Figure

When stopping cleaning for a moment, you

can use the parking aid on the back of the

vacuum cleaner.

Slide the plastic lug on the tool connector

into the groove at the back of the vacuum

cleaner.

If your cleaner has the automatic standby

function, it will now switch itself off.

=> Power indicator lights up "green".

12*

11

Figure

a)Take the mains plug, pull the mains cable

to the required length and insert the plug

into a wall socket.

b)If your unit has an electronically actuated

cable rewind, the ready indicator will now

light up green.

Figure

To switch your vacuum cleaner on and off,

press the On/Off button in the direction of the

arrow.

Figure

The required suction power can be selected by

adjusting the suction regulator.



Low suction range:

For vacuuming delicate fabrics, e.g.

curtains.



Moderate suction range:

For daily vacuuming of lightly soiled floors.



High suction range:

For vacuuming durable floor coverings,

hard floors and for heavily soiled surfaces.

Vacuuming

You have bought an extremely powerful

device.

The highest suction setting is therefore only

recommended for heavily soiled, short-pile

carpets and hard floors.

Figure

Adjusting the floor tool:



For cleaning rugs

and carpets =>



For cleaning hard floors =>

Floor nozzle with carpet lifter*

Figure

When you pull the floor tool backwards,

the rug is lifted, allowing you to clean

underneath its edge.

10*

9

8

7

6

en

*

Depending on equipment

en

Disposal information



Packaging

The packaging is designed to protect the

vacuum cleaner from being damaged

during transportation.

It is made of environment-friendly materials

and can be recycled.

Dispose of packaging that is no longer

required at an appropriate recycling point.



Used vacuum cleaners

Used vacuum cleaners contain many

recyclable materials.

Therefore, please take used vacuum

cleaners to your retailer or recycling centre

so that they can be recycled.

For current disposal methods, please

enquire at your appliance dealership or

local council.

!

Please note

Only connect the appliance to a socket

that is protected by at least a 16 amp fuse.

If a fuse should be tripped when you

switch on the vacuum cleaner, this may be

because other electrical appliances which

have a high current draw are connected to

the same power circuit.

To prevent the fuse from tripping, select the

lowest power setting before switching the

vacuum cleaner on, and increase the

power only once it is running.

Fold out picture pages.

Setting up

Figure

a)Push the hose connector into the opening

on the vacuum cleaner until it engages.

b)To remove the flexible hose, press the two

lugs together and pull the tube out.

Figure

a)Connect the handle and the telescopic

tube together.

b)Push the handle into the telescopic tube

until it engages.

To release the connection, squeeze the

collar sleeve and pull the handle out.

Figure



Attach the carpet lifter to the nozzle.



Press the carpet lifter sideways to engage.

Figure

a)Connect the floor tool and the telescopic

tube together.

b)Push the telescopic tube into the

connecting piece of the floor tool until it

engages.

Press on the locking collar and pull out the

telescopic tube to disconnect.

Figure

To adjust the length of the telescopic tube,

press the adjusting button/adjusting sleeve

in the direction of the arrow and adjust the

tube to the required length.

5*

4*

3*

2*

1
