Manual Sony Bravia KD-65AG9 Televizor OLED

Manual

3

GB

GB

Installation/Set-up

Install and use the TV set in accordance with the instructions

below in order to avoid any risk of fire, electric shock or damage

and/or injuries.

Installation

• The TV set should be installed near an easily accessible mains

socket.

• Place the TV set on a stable, level surface to prevent it from

falling over and causing personal injury or property damage.

• Install the TV where it cannot be pulled, pushed, or knocked

ov

er.

• Install the TV so that the TV’s Table-Top Stand does not protrude

out from the TV stand (not supplied). If the TV’s Table-Top Stand

protrudes out from the TV stand, it may cause TV set to topple

over, fall down, and cause personal injury or damage to the TV.

• For safety reasons, be sure to attach the centre covers to the

r

ear of the TV when TV in Table-Top condition.

• Only qualified service personnel should carry out wall-mount

installations.

• For safety reasons, it is strongly recommended that you use

S

ony accessories, including:

 Wall-Mount Bracket SU-WL850

 Wall-Mount Bracket SU-WL450

• Be sure to use the screws supplied with the Wall-Mount Bracket

when attaching the Wall-Mount Bracket to the TV set. The

supplied screws are designed as indicated by illustration when

measured from the attaching surface of the Wall-Mount Bracket.

The diameter and length of the screws differ depending on the

W

all-Mount Bracket model.

Use of screws other than those supplied may result in internal

damage to the TV set or cause it to fall, etc.

Transporting

• Before transporting the TV set, disconnect all cables.

• Two or three people are needed to transport a large TV set.

• When transporting the TV set by hand, hold it as shown below.

Do not put stress on the panel and the frame around the screen.

• When handling or mounting the

T

V set, do not lay down the TV.

• When transporting the TV set, do

not s

ubject it to jolts or excessive vibration.

• When transporting the TV set for repairs or when moving, pack

i

t using the original carton and packing material.

Topple prevention

Ventilation

• Never cover the ventilation holes or insert anything into the

cabinet.

• Leave space around the TV set as shown below.

• It is strongly recommended that you use a Sony Wall-Mount

Br

acket in order to provide adequate air circulation.

Installed on the wall

Safety Information

Screw (M6)

Wall-Mount Bracket

9 mm - 13 mm

TV’s rear cover

M4 screw (not supplied)

1.5 N·m

{15 kgf·cm}

Screw (not supplied)

6 mm - 7 mm

Cord (not

supplied)

30 cm

10 cm

10 cm

10 cm

Leave at least this much space around the set.

1 cm
