Manual Stanley TLM165 Telemetru digital

Manual

12

GB

ALWAYS remove batteries if the device will

not be used for several months.

NOTE: Ensure that the recommended

batteries are used.

NOTE: Ensure the batteries are inserted

in the correct manner, with the correct

polarity.

Loading Batteries

1.

Pull up the endpiece on the back of the tool

(Figure

D

1

).

2.

Pull up the battery compartment latch on the back

of the tool (Figure

D

2

and

D

3

).

3.

Insert three AAA batteries, making sure to position

the - and + ends of each battery as noted inside

the battery compartment (Figure

D

4

).

4.

Push the battery door down until it snaps in place

(Figure

D

5

).

When the tool is ON, the battery level appears on the

screen (Figure

E

1

).

Turning the Tool On

1.

Point the tool's laser (Figure

A

1

) toward a wall

or object, and not toward anyone's eyes.

2.

Click (Figure

A

3

) to turn the tool on and

display the red laser dot.

Choosing the Settings

Setting Automatic Turn Off

By default, the tool will automatically turn off 90

seconds after no buttons or options have been

selected. To change when the tool turns off

automatically, follow these steps.

1.

On the touchscreen, click (Figure

E

8

).

2.

On the Settings Menu (Figure

H

), click .

3.

Select the time.

• Choose to turn the tool off after 30 sec, 60 secs,

90 secs, or 300 secs.

• To keep the tool turned on until you manually

turn it off (by pressing and holding

for

10 seconds), click

∞

.

4.

Click to return to the previous screen.

Setting Screen Brightness

By default, the tool's screen will be set at 25%

brightness. To change the brightness level, follow

these steps.

1.

On the touchscreen, click (Figure

E

8

).

2.

On the Settings Menu (Figure

H

), click .

3.

Select the desired brightness level: 25%, 50%,

75%, or 100%.

4.

Click to return to the previous screen.

Turning Off the Sound

By default, the tool will beep each time you take

a measurement. You can turn off the beeps.

1.

On the touchscreen, click (Figure

E

8

).

2.

On the Settings Menu (Figure

H

), click to

display

.

3.

Click to return to the previous screen.

Changing the Unit of Measure

ft/m

By default, the tool will display measurements in

meters (1.8940 m). You can change the unit of

measure to fractional ft (6'02"

9/16), inches (74 9/16 in),

decimal ft (6.21 ft), or decimal inches (3.21 in).

1.

On the touchscreen, click (Figure

E

8

).

2.

On the Settings Menu (Figure

H

), click ft/m.
