OPERATION

Operation

ENGLISH

www.stiebel-eltron.com CWM P | CWM U | 5

4.1 Programming unit

The programming unit is located at the top right of the appliance.

D0000068106

2

1

1 Display

2 User interface

4.1.1 User interface

Button Designation Description

"Standby" key

Switch on the programming unit;

Put programming unit and heating appliance

into standby mode

"OK" button

Selection;

Confirm settings

"Menu" key

Call up and exit menu

"+" key

Call up menu items;

Change settings

"–" key Call up menu items;

Change settings

4.1.2 Display

If no user action occurs for 20seconds, the backlight switches

off. Press any button to switch the background lighting on again.

Symbols

Symbol Description

Time display:

Indication of the current time or a programmed start time

Timer mode:

The appliance heats in accordance with the enabled time pro-

gram.

Comfort mode:

The appliance maintains the set comfort temperature.

Standard setting: 21.0°C. Use this setting for comfortable room

temperatures when someone is present.

Setback mode:

The appliance maintains the set setback temperature.

Standard setting: 18.0°C. Use this setting e.g. at night or when

absent for several hours.

Frost protection:

The frost protection symbol is displayed if the set room tempera-

ture is set to 7.0°C.

Use this setting to protect an unused room from frost damage.

Adaptive start:

In timer mode, the heating appliance switching times are adjust-

ed to ensure that, at the programmed start time, the respective

set room temperature is already reached.

Conditions: The "adaptive start" function is enabled (see chapter

"Settings/ Standard menu").

Symbol Description

Window open detection:

To avoid unnecessary energy consumption while venting, the

appliance automatically switches to frost protection mode for

one hour when a window is open. The "window open detection"

symbol flashes. After venting, frost protection mode can be termi-

nated manually by pressing "+". The appliance then heats to the

set room temperature again.

Conditions: Window open detection is enabled (see chapter "Set-

tings/ Standard menu").

User interface lock:

To lock or unlock the user interface, press and hold "+" and "–"

simultaneously for 5seconds.

Heating enabled:

The appliance is heating to maintain the set room temperature.

Room temperature display

Editable parameter:

The parameter shown can be changed using "+" and "–".

External input (FP):

CWMU series appliances can be connected to an external control

unit. Depending on the control unit settings, the appliance heats

at specific times of the day in comfort, setback or frost protection

mode, or does not heat at all.

Days of the week:

1=Monday, 2=Tuesday … 7=Sunday

4.2 Switching the appliance on and off

Note

For a short time after initial start-up and after longer

breaks in use, a smell may develop.

The appliance is ready for operation as soon as it has been fixed

to the wall and plugged into the mains.

f Switch the appliance on or off using the ON/OFF switch on

the right-hand side of the appliance.

f Switch the appliance off when not in use for longer periods

(e.g. during the summer months).

All settings remain intact after switching off or after an interrup-

tion to the power supply. This appliance is equipped with a power

reserve that ensures the day of the week and the time are saved

for several hours.

Note

If the appliance was in timer mode before being switched

off for a longer period of time, you will be prompted to set

the day and time after switching it on. Until this setting

is made, the appliance will operate in comfort mode.

4.3 Standby mode

!

Material losses

In standby mode, the appliance will not switch on heating

under any circumstances. There will be no frost protec-

tion.

f To switch on the programming unit, press "Standby". The

standard display appears.

f To put the programming unit and the heating appliance into

standby mode, press "Standby". The display shows "- - - -".
