EN
HOW TO CONNECT YOUR PURIFIER TO INTERNET
Download the app "Pure Air by Rowenta" & follow the instructions on your smartphone :
1. Sign in to create your
Rowenta account if you are
new. Or log in the app if you
already have an account.
2. Make sure to stand close to
the purifier during the pairing
(2 meters maximum) and make sure
the purifier is located near a strong
Wi-Fi signal.
3. Make sure your phone is connected
to your local Wi-Fi network
4. Turn your purifier on & hold
the Wi-Fi button for 3 seconds
(you'll hear a "ding" sound and
the Wi-Fi indicator will flash to
indicate that your purifier is
successfully connected to Wi-Fi.)
5. Choose your Wi-Fi network and
enter the network password to
connect to your local Wi-Fi network.
6. And you’re done !
The Wi-Fi indicator lights to indicate
that your purifier is successfully
connected to your Pure air by
Rowenta app.
Wi- function
To launch a new pairing press the WIFI button for 3 seconds.
• When the light is on, the product is paired/connected.
• When the light is flashing quickly then slowly, the product is pairing/connecting to the WIFI/servers.
• When the light is off, the product is not connected.
To turn off the Wi-Fi function, hold simultaneously the WIFI
+ TIMER buttons during 4 seconds.
To turn it back on, press the WIFI button
for 3 seconds.
Product reset
You can do the reset on the product (with the air quality box plugged on it) :
1. Press together the TIMER
+ ALLERGEN MODE buttons for 8 seconds
2. First, the appliance will make a bip to indicate Reset is launched. Then the appliance will erase all data
regarding pairing.
3. Once it’s done, the product will make a long bip and turn off.
4. Unplug and replug the main unit to finalize the reset procedure
Or on the air quality box :
1. Go into settings (refer to section « Air Quality Box »)
2. Select « reset the product »
3. Press « validate »
4. First, the appliance will make a bip to indicate Reset is launched. Then the appliance will erase all data
regarding pairing.
5. Once it’s done, the product will make a long bip and turn off.
6. Unplug and replug the main unit to finalize the reset procedure
Note : this resets the product including the wifi connection settings.
Connection issues
In case of pairing issues between the appliance and your domestic Wi-Fi network, refer to the information listed
on the following link:
https://www.compatibility.groupeseb.com/CompatibilityList-Pureair-Rowenta.pdf
https://www.compatibility.groupeseb.com/CompatibilityList-Pureair-Tefal.pdf
5. OPERATION
INDICATION OF AIR QUALITY
There are 3 sensors on the product : PM (2,5/10), VOC, & humidity.
Your product will compute a global measurement of air quality level based on the VOC & particles values through
a dedicated algorythmn giving you this 5 Air Quality Index :
Air Quality Air quality indicator color
Excellent Blue
Slight pollution Green
Moderate pollution Yellow
High pollution Orange
Extreme pollution Red
MAIN PURIFIER FUNCTIONS
Power button (4) : Plug the product in the power socket. Press the power button to switch the air purifier
on or off.
NB : The last mode or speed is memorized when the product is put in stand-by/switched off.
Timer button
(6) : Press this button to launch the timer. You can select 1h,2h,4h or 8h.
NB : When the box is unplugged, the timer still runs on the purifier. A timer set directly on the product will prevail over
a previous scheduling set on the app.
Speed button
(7) : Press this button to manually select the desired speed. There are 10 speeds available
including silent speed (speed 1) and turbo speed (speed 10).
NB : It is still possible to select the speeds when the air quality box is unplugged but the speed selection will only be
visible on the app during that time.
Mode button
(8) : Press this button to select one of these two modes : AUTODAY and AUTONIGHT.
On AUTODAY and AUTONIGHT mode : if the air quality level is excellent then the device does not run.
- Daytime auto-mode : the fan speed is set to 1,3,5 or 7.
- Night time auto-mode : the fan speed is set to 1,2 or 3.
NB : These two modes are only available when the air quality box is plugged on the product.
Allergen mode button (9) :
Press this button to select the allergen mode. It is a special mode with increased
sensor sensivity and increased speed compared to AUTODAY mode. In this mode the fan speed is set to 1,3,5,7 or 9.
NB : This mode is only available when the air quality box is plugged on the product.
