THANK YOU FOR BUYING AN INDESIT PRODUCT.

In order to receive a more complete assistance,

please register your product on

www.register10.eu

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code in your appliance

• Visiting our website docs.indesit.eu and parts-selfservice.europeanappliances.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales

Service, please state the codes provided on your product's identification plate.

You can find more information about your model online at https://eprel.ec.europa.eu/ which is the official EU EPREL product database.

After selecting the Product Category, enter the Model Identifier of the product. The Model Identifier is made up of letters and numbers

and can be found on the identification plate, as Mod. (see image on the right).

EN

Before using the appliance carefully

read the Safety Instruction.

PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.

Quick guide

Before using the appliance carefully

read the Safety Instruction.

Power consumption

off-mode (Po) - Watts 0.42

left-on mode (Pl) - Watts 2.00

Programs Kg kWh Minutes

Eco *

8 1.95 194

Eco

4 1.06 135

Synthetics 4 0.73 95

*The ECO is the most efficient programme in terms of energy

consumption for drying wet cotton laundry, and is used to assess

compliance with Regulation (EU) 932/2012.

Cleaning the tumble dryer

• The external metal, plastic and rubber parts can be cleaned

with a damp cloth.

• Clean the front air intake grille regularly (every 6 months) with

a vacuum cleaner to remove any lint, fluff or dust deposits.

Furthermore, remove any lint deposits from the filters area,

using a vacuum cleaner every so often.

• Do not use solvents or abrasives.

AB

1

4

2

3

C

C1 C2 C3

C4

C5

C6

CLEANING AND MAINTENANCE

WARNING: unplug the dryer during the cleaning and

maintenance procedures.

Emptying the water tank after each cycle (see Fig. A).

Pull the container out of the dryer and empty it into a sink or other

suitable drain, then place it back properly. Do not use the dryer

without having inserted the container back in place.

Cleaning the lters

Take out the filters and clean them by removing the lint from their

surfaces with your hand or a cloth or using a vacuum cleaner, then

put them back in place. The lint should be thrown in the garbage

bin and not washed through the drain in order to avoid spreading

microplastics in the used water system.

Do not use the dryer without having reinserted the lter in place.

Cleaning the door lter after each cycle (see Fig. B).

Remove the door filter as described below:

1. Open the door and pull the filter upwards.

2. Open the filter and remove the lint from all its parts.

Make sure to also remove any foreign objects inside the

filter and

the drum.

Replace the filter correctly making sure it is fully seated.

Cleaning the bottom lter when the relevant indicator

turns on (see Fig. C).

NOTE: however, it is advisable to clean this filter after each cycle

to optimise drying performance.

Remove the bottom filter as described below:

C1. Open the bottom cover; take the handle and pull the filter out.

C2. Open the rear side of the filter and remove the lint from the

inner surface of the mesh.

C3/C4. Check the bottom filter chamber every month. If you

see residual lint accumulated on the metal fins, clean it with a

vacuum cleaner, using a nozzle with a brush.

It's crucial to do vertical movements, you may destroy the

component if you try to clean it in horizontal direction. Avoid the

direct contact of the hand with the fins - risk of cut.

C5. Close the rear side of the filter and place it back by checking it

is perfectly integrated into its seat, then lower the filter handle.

C6. Close the bottom cover.

Make sure the air intake is free.

The lters are essential parts for drying. They are intended

to collect the lint formed during the drying process. In case

of clogged lters, the air ow inside the dryer would be

seriously aected: the drying times would be longer, the

energy consumption would increase and the dryer could be

PRODUCT DESCRIPTION

1. Water Tank

2. Air Intake

3. Bottom filter

4. Door filter

TRANSPORT AND HANDLING

Never lift the dryer by holding it at the worktop.

1. Unplug the dryer.

2. Remove the water from the water tank completely.

3. Make sure that door and water tank are properly closed.

4. If the drain hose is connected to your drainage system,

re-connect it to the back of the dryer (see "Installation" section

in the Safety Instruction guide).

damaged. If these procedures are not carried out properly,

the dryer may not start.

NOTE: After cleaning the filters the relevant indicator remains on;

this is normal, it will disappear when you start a new drying cycle.
