Manual Whirlpool W9 921A OX Combina frigorifica

Manual

EN

Quick guide

* Available only on certain models

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

register your product on www . whirlpool . eu/ register

Before using the appliance carefully read the Safety

Instruction.

FIRST TIME USE

After installation, wait at least two hours before connecting the

appliance to the power supply. Once connected, it will start working

automatically. The ideal temperature settings are preset from the factory.

After turning the appliance on, wait 4-6 hours for it to reach the correct

food storage temperature.

CONTROL PANEL

1. Smart display indicator

2. Door open indicator

3. Black-out alarm indicator

4. Fast Cool indicator

5. Fridge temperature display (°C)

6. Vacation Mode indicator

7. Precision control indicator

8. Fast Freeze indicator

9. Freezer temperature display (°C)

10. On/Standby button

11. Stop Alarm button

12. Fridge temperature button (°C) / Fast Cool button

13. Party Mode button / Vacation Mode button

14. Freezer temperature button (°C) / Fast Freeze button

ON/STANDBY

To put the product in Standby, press and hold the On/Standby button

for 3 seconds. All the indicators turn o except On/Standby indicator.

In Standby mode the light in the refrigerator compartment does not

turn on.

Press again to reactivate the appliance.

FRIDGE TEMPERATURE

To adjust the fridge temperature, press the Fridge °C button. The fridge

temperature can be adjusted between +2°C and + 8°C, as shown by

the fridge/freezer temperature display. Recommended setting for the

refrigerator compartment is +4°C

FREEZER TEMPERATURE

To adjust the freezer temperature, press the Freezer °C button.

The freezer temperature can be adjusted between -16°C and -24°C, as

shown by the the fridge/freezer temperature display.

Recommended setting for the freezer compartment is -18°C.

FAST COOL

Using Fast Cool function it is possible to increase the cooling

capacity in the refrigerator compartment. The use of this function

is recommended when placing a very high quantity of food in the

refrigerator compartment.

Press the fridge temperature button/ Fast Cool button for 3 sec to

activate Fast Cool function. When activated, the Fast Cool indicator

turns on. The function is automatically disabled after 6 hours, or can be

manually disabled by pressing the fridge temperature button button/

Fast Cool button again for 3 sec.

FAST FREEZE

The use of this function is recommended when placing a very high

quantity of food to be frozen in the freezer compartment.

24 hours before freezing fresh food, press the freezer temperature

button /Fast Freeze button for 3 sec to activate the Fast Freeze

function. When activated, the Fast Freeze indicator turns on. After

24 hours place the food to be frozen in the bottom freezing zone

of freezer compartment. The function is automatically disabled

after 48 hours, or can be manually disabled by pressing the freezer

temperature button / Fast Freeze button again for 3 sec.

PARTY MODE

Press the Party Mode button to activate the Party Mode function. The

Party Mode icon turns on.

Use this function to chill drinks inside the freezer compartment.

Important: do not leave the bottle inside the freezer compartment

longer than the function is active (30 minutes).

The function can be manually disabled by pressing the Party Mode

button, before the acoustical alarm turns on.

After 30 min since it has been engaged, the acoustical alarm is

activated, the party mode icon and the alarm indicator blink Press the

Stop Alarm button to exit party mode.

VACATION

You can use this function in the event of a prolonged absence from

home. Press the Vacation button for 3 sec to engage Vacation Mode.

The display will show the temperature of the refrigerator compartment

(+12°C) and the Vacation mode icon will light up. After activating

this function, remove the food from the refrigerator compartment

and keep both doors closed - the refrigerator will maintain a suitable

temperature to prevent odours from forming. The freezer, however,

remains at the temperature originally set. A deep clean (of both

refrigeration and freezer compartment) is recommended before

activating this function in order to prevent the spread of bacteria.

Press again the same button for 3 sec to deactivate Vacation.

Changing the setpoint will automatically deactivate the function.

SMART DISPLAY

This function is active by default and turns o the LEDs on the user

interface 15 sec after the last interaction with the user interface and/or

with the door.

When activated, other buttons and the displays are switched o except

the smart display icon The function can be manually deactivated by

pressing the Stop Alarm button for 5 sec.

To reactivate this function repeat the same procedure. Remember

that this function does not disconnect the appliance from the power

supply, but only reduce the power consumed by external display Every

time you want to use the control panel and see all the functions, you

just need to touch any button to wake up the panel.

PRECISION CONTROL FUNCTION

This is an advanced technology that reduces temperature uctuations

in the whole freezer compartment. Freezer burns are reduced and food

preserves its original quality and color. This function is automatically

engaged when the freezer temperature set-point is between -22°C and

-24°C. This is signaled by Precision control indicator.

If the function is engaged and the user modies the freezer

temperature out of the working range, the function is automatically

switched o.
