14 /36 EN

Refrigerator / User Guide

3 Installation

3.1. Right place for installation

Contact the Authorized Service for the product's

installation. To ready the product for installation, see

the information in the user guide and make sure the

electric and water utilities are as required. If not, call

an electrician and plumber to arrange the utilities as

necessary.

B

WARNING: The manufacturer assumes

no responsibility for any damage caused

by the work carried out by unauthorized

persons.

B

WARNING: The product’s power cable

must be unplugged during installation.

Failure to do so may result in death or

serious injuries!

A

WARNING: If the door span is too narrow

for the product to pass, remove the door

and turn the product sideways; if this does

not work, contact the authorized service.

• Place the product on a flat surface to avoid vibration.

• Place the product at least 30 cm away from the

heater, stove and similar sources of heat and at least

5 cm away from electric ovens.

• Do not expose the product to direct sunlight or keep

in damp environments.

• The product requires adequate air circulation to

function efficiently.

• If the product will be placed in an alcove, remember

to leave at least 5 cm distance between the product

and the ceiling and the walls.

• Do not install the product in environments with

temperatures below -5°C.

• Your product requires adequate air circulation to

function efficiently. If the product will be placed in an

alcove, remember to leave at least 5 cm clearance

between the product and the ceiling, rear wall and

the side walls.

• If the product will be placed in an alcove, remember

to leave at least 5 cm clearance between the

product and the ceiling, rear wall and the side

walls. Check if the rear wall clearance protection

component is present at its location (if provided with

the product). If the component is not available, or

if it is lost or fallen, position the product so that at

least 5 cm clearance shall be left between the rear

surface of the product and the wall of the room.

The clearance at the rear is important for efficient

operation of the product.

3.2. Attaching the plastic wedges

Use the plastic wedges in the provided with the product

to provide sufficient space for air circulation between the

product and the wall.

1.

To attach the wedges, remove the screws on the product

and use the screws provided with the wedges.

2.

Attach 2 plastic wedges on the ventilation cover as shown

in the figure.

3.3. Adjusting the stands

If the product is not in balanced position, adjust the

front adjustable stands by rotating right or left.

3.4. Power connection

A

WARNING: Do not use extension or multi

sockets in power connection.

B

WARNING: Damaged power cable must

be replaced by Authorized Service.

C

When placing two coolers in adjacent

position, leave at least 4 cm distance

between the two units.

• Our firm will not assume responsibility for any

damages due to usage without earthing and power

connection in compliance with national regulations.

• The power cable plug must be easily accessible

after installation.

• Do not use multi-group plug with or without

extension cable between the wall socket and the

refrigerator.

C

Hot Surface Warning!

Side walls of your product is equipped

with refrigerant pipes to improve the

cooling system. Refrigerant with high

temperatures may flow through these

areas, resulting in hot surfaces on the

side walls. This is normal and does not

need any servicing. Please pay attention

while touching these areas.
