English | 23

GWS 17-125

CIX

GWS 15-125

CIPX

GWS 17-125

CIEX

GWS 15-125

CIEPX

K m/s

2

1.5 1.5 1.5 1.5

The vibration level given in these instructions has been

measured in accordance with a standardised measuring pro-

cedure and may be used to compare power tools. It can also

be used for a preliminary estimation of exposure to vibra-

tion.

The stated vibration level applies to the main applications of

the power tool. However, if the power tool is used for differ-

ent applications, with different application tools or poorly

maintained, the vibration level may differ. This can signific-

antly increase the exposure to vibration over the total work-

ing period.

To estimate the exposure to vibration accurately, the times

when the tool is switched off or when it is running but not ac-

tually being used should also be taken into account. This can

significantly reduce the exposure to vibration over the total

working period.

Implement additional safety measures to protect the oper-

ator from the effects of vibration, such as servicing the

power tool and application tools, keeping the hands warm,

and organising workflows correctly.

Fitting

Fitting protective equipment

u Pull the plug out of the socket before carrying out any

work on the power tool.

Note: If the grinding disc breaks during operation or the

holding fixtures on the protective guard/power tool become

damaged, the power tool must be sent to the after-sales ser-

vice immediately; see the "After-Sales Service and Applica-

tion Service" section for addresses.

Protective guard for grinding

Place the protective guard

(8) onto the holder on the

power tool until the coding

cams of the protective

guard are aligned with the

holder. When doing so,

press and hold the unlock-

ing lever (1).

Press the protective guard

(8) onto the spindle collar

until the shoulder of the

protective guard is sitting

on the flange of the power

tool and rotate the protect-

ive guard until it audibly

clicks into place.

Adjust the position of the protective guard (8) to meet the

requirements of the operation. To do this, push the unlock-

ing lever (1) upward and rotate the protective guard (8) into

the required position.

u Always position the protective guard (8) such that all

three red cams on the unlocking lever (1) engage in

the corresponding openings on the protective guard

(8).

u Adjust the protective guard (8) such that sparking in

the direction of the operator is prevented.

u The protective guard (8) must only be adjustable

while the unlocking lever (1) is actuated. Otherwise,

the power tool must not be used any more under any

circumstances and must be sent to the after-sales ser-

vice.

Note: The coding cams on the protective guard (8) ensure

that only a protective guard that is suitable for the power

tool can be fitted.

Extraction guard for sanding

The extraction guard (7) can be used to minimise dust when

sanding paint, varnish and plastics in conjunction with the

carbide grinding head (11). The extraction guard (7) is not

suitable for working metals.

A suitable Bosch vacuum cleaner can be connected to the

extraction guard (7).

The extraction guard (7) is mounted in the same manner as

the protective guard (8). The brush collar can be replaced.

Protective guard for cutting

u Always use the protective guard for cutting (9) when

cutting bonded abrasives.

u Provide sufficient dust extraction when cutting stone.

The protective guard for cutting (9) is fitted in the same way

as the protective guard for grinding (8).

Extraction guard for cutting with a guide block

The extraction guard for cutting with a guide block (19) is fit-

ted in the same way as the protective guard for grinding.

Hand guard

u Always fit the hand guard (21) when working with the

rubber sanding plate (22) or with the cup brush/disc

brush/flap disc.

Attach the hand guard (21) to the side handle (6).

Side handle

u Do not operate your power tool without the side

handle (6).

u Do not continue to use the power tool if the auxiliary

handle is damaged. Do not make any alterations to the

auxiliary handle.

Screw the side handle (6) on the left or right of the machine

head depending on how your are working.

Bosch Power Tools 1 609 92A 5WT | (12.08.2020)
