Manual Bosch GWS 15-125 CIPX Professional Polizor unghiular

Manual

26 | English

after-sales service immediately; see the "After-Sales Service

and Application Service" section for addresses.

Kickback stop

If there is a sudden kickback in the power tool,

e.g. jamming in a separating cut, the power

supply to the motor will be interrupted elec-

tronically.

To restart the tool, set the On/Off switch (3) to the "off" po-

sition and then switch the power tool on again.

Restart protection

The restart protection feature prevents the power tool from

uncontrolled starting after the power supply to it has been

interrupted.

To restart the tool, set the on/off switch (3) to the off posi-

tion and then switch the power tool on again.

Starting current limitation

The electronic starting current limitation feature restricts the

power of the power tool when it is switched on and enables

operation using a 16 A fuse.

Note: If the power tool runs at full speed immediately after

being switched on, this means that the starting current limit-

ation and restarting protection mechanisms have failed. The

power tool must be sent to the after-sales service immedi-

ately; see the "After-Sales Service and Application Service"

section for addresses.

Constant Electronic control

The Constant Electronic keeps the speed at no load and un-

der load virtually consistent, guaranteeing uniform perform-

ance.

Speed preselection

(GWS 13-125 CIEX / GWS 12-125 CIEPX /

GWS17-125CIEX/GWS15-125CIEPX)

You can preselect the required speed using the speed

preselection thumbwheel (4), even during operation. The in-

formation in the table below describes the recommended

values.

Material Application Application tool Thumbwheel position

Metal Removing paint Sanding sheet 2−3

Wood, metal Removing rust Sanding sheet 3

Metal, stone Grinding Grinding disc 4−6

Metal Rough grinding Grinding disc 6

Metal Cutting Cutting disc 6

Stone Cutting Diamond cutting disc and cutting

guide (cutting of stone is permit-

ted only with a cutting guide)

6

The values specified for speed levels are guide values.

u The rated speed of the accessory must be at least

equal to the maximum speed marked on the power

tool. Accessories running faster than their rated speed

can break and fly apart.

Working advice

u Pull the plug out of the socket before carrying out any

work on the power tool.

u Exercise caution when cutting slots in structural walls;

see the "Information on structural design" section.

u Clamp the workpiece if it is not secure under its own

weight.

u Do not load the power tool so heavily that it comes to a

stop.

u If the power tool has been subjected to a heavy load,

continue to run it at no-load for several minutes to

cool down the accessory.

u Do not use the power tool with a cut-off stand.

u Do not touch grinding and cutting discs until they have

cooled down. The discs can become very hot while work-

ing.

Flap Disc

With the flap disc (accessory), curved surfaces and profiles

can be worked. Flap discs have a considerably higher ser-

vice life, lower noise levels and lower sanding temperatures

than conventional sanding sheets.

Rough grinding

u Never use cutting discs for rough grinding.

The best rough grinding results are achieved with a set angle

of 30° to 40°. Move the power tool back and forth with mod-

erate pressure. This will ensure that the workpiece does not

become too hot or discolour and that grooves are not

formed.

Cutting Metal

u Always use the protective guard for cutting (9) when

cutting bonded abrasives.

When carrying out abrasive cutting, use a moderate feed

that is suited to the material being machined. Do not exert

pressure on the cutting disc and do not tilt or swing the

power tool.

Do not attempt to reduce the speed of a cutting disc coming

to a stop by applying pressure from the side.

1 609 92A 5WT | (12.08.2020) Bosch Power Tools
