How is blood pressure measured?

This medisana blood pressure monitor is a device, which is used to measure blood

pressure at the upper arm. The measurement is carried out by a microprocessor

- already during the inating process of the cu󰀨. The device detects the systole

and the measurement is completed earlier than using conventional measurement

methods. As a result, an unnecessarily excessive ination pressure in the cu󰀨 is

prevented. Additionally, your device is able to recognize unregular heartbeat (so-

called arrhythmia), which may a󰀨ect the measurements. In case an arrhythmia

has been deteced, the respective symbol will appear in the display of the unit.

Blood pressure classication

Wrap the cu󰀨 properly. Loosen

the clothing on the arm.

Remeasure in correct way.

Wrap the cu󰀨 properly.

Remeasure in correct way.

Wrap the cu󰀨 properly.

Remeasure in correct way.

Relax for a moment. Refasten

the cu󰀨 and measure again.

If the problem persists, contact

your physician.

Out of measurement

range

Pulse cannot be

detected

Weak batteries

No display

Error messages and error remedying

CauseDisplay

DE/GB

0297

WARNING

Blood pressure that is too low represents just as great a

health risk as blood pressure that is too high! Fits of dizziness

may lead to dangerous situations arising (e.g. on stairs or in

tra󰀩c)!

Inuencing and evaluating readings

• Measure your blood pressure several times, then record and compare the

results. Do not draw any conclusions from a single reading.

• Your blood pressure readings should always be evaluated by a doctor who is

also familiar with your personal medical history. When using the unit regularly

and recording the values for your doctor, you should visit the doctor from time

to time to keep him updated.

• When taking readings, remember that the daily values are inuenced by

several factors. Smoking, consumption of alcohol, drugs and physical exertion

inuence the measured values in various ways.

• Measure your blood pressure before meals.

• Before taking readings, allow yourself at least ve minutes rest.

• If the systolic and diastolic readings seem unusual (too high or too low) on

several occasions, despite correct use of the unit, please inform your doctor.

This also applies to the rare occasions when an irregular or very weak pulse

prevents you from taking readings.

Getting started

Inserting/changing batterie

You must insert the batteries provided before you can use your unit. The lid of the

battery compartment

3

is located on the underside of the unit. Open it, remove

it and insert the 4 x 1,5 V batteries, type AAA / LR03 supplied. Ensure correct

polarity when inserting the batteries (as marked inside the battery compartment).

Close the battery compartment. Replace the batteries if the change battery

symbol

u

appears on the display

9

or if nothing appears on the display after

the unit has been switched on.

Settings

1. Date and time

When unit is switched o󰀨, press SET

7

. The time will be displayed. Now press

and hold the SET button

7

, until the year gure starts to ash for setting. Keep

pressing the MEM button

6

until the actual year gure appears. Press SET

7

to conrm the year. Afterwards, you can proceed with the month/date setting,

followed by the time format setting (12 or 24 hours), as well as hours and minutes.

Adjust the corresponding gures accordingly. When nished, “dOnE” appears on

the display along with the adjusted values. Afterwards, the device will switch o󰀨.

2. User memory setting

The medisana blood pressure monitor features 2 separate memories, each with

a capacity of 250 memory slots. By pressing the user memory button

5

when the

device is switched on, you may choose between user and user . The display

shows the current selection

o

.

Fitting the cu󰀨

1. Connect the air hose to the connector

1

on the left side of the device.

2. Slide the open end of the cu󰀨 through the metal bracket so that the Velcro

fastener is on the outside and it becomes a cylindrical form (Fig.1). Slide the

cu󰀨 over your left upper arm.

3. Position the air hose in the middle of your arm in line with your middle nger

(Fig.2) (a). The lower edge of the cu󰀨 should be 2 - 3 cm above the crease of

the elbow. (b). Pull the cu󰀨 tight and close the Velcro fastener (c).

4. Measure the blood pressure on your bare arm.

5. Only position the cu󰀨 on the right arm if it cannot be used on the left arm.

Always carry out measurements on the same arm.

6. Correct measuring position for sitting (Fig.3).

IMPORTANT

Follow the instructions for use!

Non-observance of these instructions

can result in serious injury or damage

to the device.

WARNING

These warning notes must be observed

to prevent any injury to the user.

CAUTION

These notes must be observed to

prevent any damage to the device.

NOTE

These notes give you useful additional

information on the installation or

operation.

Device classication: type BF applied

part

LOT number

Manufacturer

Date of manufacture

SN

Serial number

Common factors of wrong measurements

• Please keep quiet for 5-10 minutes and avoid

eating, drinking alcohol, smoking, exercising and

bathing before taking a measurement. All these

factors will inuence the measurement result.

• Remove any garment that ts closely to your

upper arm.

• Always measure on the same arm (normally left).

• Measurements should be taken regularly at the

same time of each day, as the blood pressure

varies even during the day.

• Any e󰀨ort to support the arm during measurement

may increase the measured blood pressure.

• Make sure, you are in a comfortable, relaxed

position and do not move or constrict your

muscles during measurement. Use a cushion to

support your arm if necessary.

• If the arm artery lies lower or higher than the

heart, a false reading will be obtained.

• A loose or open cu󰀨 causes false readings.

• With repeated measurements, blood accumulates

in the arm which can lead to false reading.

Consecutive blood pressure measurements

should be repeated after 3 minutes pause or after

the arm has been held up in order to allow the

accumulated blood to ow away.

• The unit is intended only for private use in the home.

• The device should be placed at least 30 minutes before use in the area of use

in order to properly adapt to the room temperature. Only use the device under

the conditions mentioned in the technical details.

• Consult your doctor prior to using the blood pressure monitor if you are

concerned about health matters.

• Only use the unit for its intended purpose in accordance with the instructions

for use.

• Warranty claims become void if the unit is misused.

• The unit may not be used to check the heart rate of a pacemaker.

• Irregularity of pulse or arrhythmia can lead to di󰀩culties in recording a correct

reading when measurements are taken using oscillometric blood pressure

devices. This device is electronically equipped to detect arrhythmia which it

indicates with the icon

z

. In this case, contact your physician.

• Do not use the unit in case of existing polyester resp. synthetic allergies.

• Like on any other oscillometric blood pressure measurement devices, certain

medical conditions can a󰀨ect the measurement accuracy, among others:

cardiac arrhythmias, low blood pressure, circulatory disorders, states of shock,

diabetes, pregnancy, pre-eclampsia etc. Always consult a physician before you

use the device.

• Never apply the cu󰀨 over hurt skin.

• Do not take measurements, if any other equipment is applied to the same limb

for monitoring. This could lead to disturbances or failures.

• If you experience discomfort during a measurement, such as pain in the upper

arm or other complaints, press the START/ STOP

8

button to release the air

immediately from the cu󰀨. Loosen the cu󰀨 and remove it from your arm.

• On the rare occasion of a fault causing the cu󰀨 to remain fully inated during

measurement, open the cu󰀨 immediately. Prolonged high pressure (cu󰀨

pressure >300 mmHg or constant pressure >15 mmHg for more than 3 minutes)

applied to the arm may lead to an ecchymosis.

• Too frequent and consecutive measurements could cause disturbances in

blood circulation and injuries.

• Pay attention during use and storage, that cable and air hose will not cause

strangulation.

• Never bend the air hose during use as this may lead to injuries. Also never

squeeze or block the air hose in any way.

• Do not connect the air hose to other medical equipment, as this could cause air

to be pumped into intravascular systems or high pressure, what could lead to

dangerous injuries.

• This device is not suitable for continous monitoring during medical emergencies

or operations.

• This device cannot be used with surgical equipment at the same time.

• The unit may not be operated in the vicinity of appliances that emit strong

electric radiation such as radio transmitters or mobile phones. This may a󰀨ect

the proper functioning (see „electromagnetic compatibility“).

• This device is not intended for patient transports outside a healthcare facility.

• Do not use the equipment where ammable gas (such as anaesthetic gas,

oxygen or hydrogen) are present.

• Do not take any therapeutic measures on the basis of a self measurement.

Never alter the dose of a medicine prescribed by a doctor.

• This device is not designed to be used by persons with limited physical, sensory

or mental abilities, or by persons with insu󰀩cient experience and/or knowledge,

unless under observation by a person responsible for their safety, or unless they

have been instructed in the use of the device.

• This device is intended to be used by adults. The unit is unsuitable for children

or babies. Contact your doctor, if you want to use this device on young persons.

• Please ensure that the unit is kept away from the reach of children and pets.

The swallowing of small part like packaging bag, battery, battery cover and so

on may cause su󰀨ocation.

• Before use, make sure the device functions safely and is in proper working

condition. Do not service or maintain while the device is in use.

• Please do not attempt to repair the unit yourself in the event of malfunctions.

Only have repairs carried out by authorised service centres.

• Protect the unit from moisture. Should moisture enter the unit, remove the

batteries and stop using it immediately. In this case, please contact either your

dealer or us directly. You can nd details of how to contact us on the address

page.

• Only use original additional or spare parts from the manufacturer. Other parts

could damage the device or could lead to personal injury.

• Please report to medisana if any unexpected operation or events occur.

• If the unit is not going to be used for a long period, please remove the batteries.

BATTERY SAFETY INFORMATION

• Do not disassemble batteries!

• Renew the batteries when the battery icon appears on the display.

• Remove discharged batteries from the device immediately, because they can

leak and damage the device!

• Increased risk of leakage, avoid contact with skin, eyes and mucous membranes!

If battery acid comes in contact with any of these parts, rinse the a󰀨ected area

with copious amounts of fresh water and seek medical attention immediately!

• If a battery has been swallowed seek medical attention immediately!

• Replace all of the batteries simultaneously!

• Only replace with batteries of the same type, never use di󰀨erent types of

batteries together or used batteries with new ones.

• Insert the batteries correctly, observing the polarity!

• Keep batteries out of children‘s reach!

• Do not attempt to recharge batteries, do not short-circuit and do not throw into

a re! There is a danger of explosion!

• Do not throw used batteries into the household refuse; put them in a hazardous

waste container or take them to a battery collection point, at the shop where

they were purchased!

Unit and LC-Display

1

Connector for the hose

2

Air hose

3

Battery compartment (on back-

side)

4

Cu󰀨

5

User memory button

6

MEM - button (Memory)

7

SET - button

8

START/STOPP - button

9

LC - display

0

Display of systolic pressure

q

Display of diastolic pressure

w

Display of pulse rate

e

Time / Date

r

Bluetooth

®

- symbol

t

Ination / Deation symbol

z

Pulse / Arrhythmia display

u

Batteries low

i

Average value display

(“AVG“)

o

User memory (A/B)

p

Blood Pressure Indicator (green - yel-

low - orange - red)

a

Memory display

Taking a blood pressure measurement

After the cu󰀨 has been appropriately positioned,the measurement can begin.

1. Switch the unit on by pressing the START/STOP button

8

.

2. All display characters are shown (display test). This test can be used to

check that the display is indicating properly and in full. The unit is ready for

measurement and „0“ appears.

3. The device then automatically inates the cu󰀨 slowly in order to measure your

blood pressure. The rising pressure in the cu󰀨 is shown on the display.

4. When the device detects the signal, the heart symbol on the display starts to

ash. If a result is determined, the device slowly will release the air from the

cu󰀨. The systolic and diastolic blood pressure and the pulse value with the time

value appear on the display.

5. The blood pressure indicator

p

ashes next to the relevant coloured bar

depending on the blood pressure classication.

6. If the unit has detected an irregular heartbeat, the arrhythmia display

z

appears additionally

7. The readings are automatically saved in the selected memory ( or ).

8. The measurement results will automatically be transferred via Bluetooth

®

to

receive-ready devices. During this process, the Bluetooth

®

-symbol

r

will

ash. If the transfer was successful, the Bluetooth

®

-symbol

r

will disappear

after approx. 5 seconds. If the transfar was not successful, the symbol will

disappear after max. 3 minutes.

9. Switch o󰀨 the device using the START/STOP button

8

.

Transfer via Bluetooth

®

The medisana upper arm blood pressure monitor BU 540 connect

o󰀨ers the

possibility to transfer your measured values via Bluetooth

®

to the VitaDock

®

app.

The VitaDock

®

app allows the evaluation, storage and synchronisation of your

data between multiple iOS- and Android-devices to have access to it anytime and

anywhere. You may share your results with your friends or your doctor. Therefore

you need a free user account, which you can create on the website www.vitadock.

com. For Android or iOS mobile devices, you may download the respective apps.

You will nd a detailed instruction for how to install and use the software on the

mentioned website. After each measurement an automatic transfer of the values

will take place (provided that

Bluetooth

®

is activated and congurated on the

receiving device).

Displaying stored results

This unit features 2 separate memories, each with a capacity of 250 memory

slots. Results are automatically stored in the memory selected by the user. Press

the MEM button

6

when power o󰀨, to call up the measured values stored. The

average values of the last 3 measurements appear on the display (if already 3

measurements have been stored for the respective user. Press the MEM button

6

again to call up the last measurement value. Repeatedly pressing the MEM

button

6

displays the respective values measured in other measurements.

Memory recall mode can be exited at any time by pressing the START/STOP

button

8

, which will also switch the unit o󰀨. The oldest value is deleted if 250

measured values have been stored in the memory and a new value is saved.

Deleting memory

Press MEM-button

6

to enter the memory recall mode. If you are sure that you

want to permanently remove all stored memories, press and hold the SET button

7

for approximately 3 seconds until „dEL ALL” appears in the display. Then

press SET button again to delete all the values. The device then switches o󰀨

automatically. You may abort the deletion process by pressing the START/STOP

button

8

beforehand.

Solution

Batteries may be

exhausted or inserted

incorrectly. Check if the

power connection has

been established

properly.

Insert new batteries.

Insert the batteries according to

the instructions given.

Batteries are weak or empty.

Replace all 4 batteries by new

ones (1.5V, type AAA / LR03).

E01

E02

E03

E04

EExx

out

Cu󰀨 not properly tted

Movement or speaking

during measurement

Measurement

failed

Calibration error

(“xx“ can be a gure,

e.g. 01, 02 etc.)

Wrap the cu󰀨 properly.

Remeasure in correct way.

Rest 30 minutes and

remeasure in correct way. Do

not speak or move during the

measurement.

In accordance with our policy of continual product improvement, we

reserve the right to make technical and visual changes without

notice.

The current version of this instruction manual can be found under

www.medisana.com

Warranty and repair terms

Please contact your supplier or the service centre in case of a claim under the war-

ranty. If you have to return the unit, please enclose a copy of your receipt and state

what the defect is.

The following warranty terms apply:

1. The warranty period for medisana products is 3 years from date of purchase.

In case of a warranty claim, the date of purchase has to be proven by means of

the sales receipt or invoice.

2. Defects in material or workmanship will be removed free of charge within the

warranty period.

3. Repairs under warranty do not extend the warranty period either for the unit or for

the replacement parts.

4. The following is excluded under the warranty:

a. All damage which has arisen due to improper treatment, e.g. nonobservance of

the user instructions.

b. All damage which is due to repairs or tampering by the customer or

unauthorised third parties.

c. Damage which has arisen during transport from the manufacturer to the

consumer or during transport to the service centre.

d. Accessories which are subject to normal wear and tear.

5. Liability for direct or indirect consequential losses caused by the unit are excluded

even if the damage to the unit is accepted as a warranty claim.

medisana GmbH

Carl-Schurz-Str. 2

41460 NEUSS, GERMANY

WARNING

Please ensure that the polythene packing is kept away from

the reach of children! Risk of su󰀨ocation!

systolic

mmHg

≥ 180

160 - 179

140 - 159

130 - 139

120 - 129

< 120

≥ 110

100 - 109

90 - 99

85 - 89

80 - 84

< 80

serious

hypertension

medium

hypertension

mild

hypertension

high-normal

blood pressure

normal

blood pressure

optimal

blood pressure

Bloodpressure

Indicator

p

red

orange

yellow

green

green

green

diastolic

mmHg

WARNING

• Keep the device at least 20 centimeters away from the

human body (especially the head) when the Bluetooth

®

data

transmission is proceeding after measurement.

• The distance between the device and the receiver should be

between 1 meter to 10 meters to avoid possible disturbances.

• To avoid interference with other electronic devices, these

should be kept at least 1 meter away from the monitor.

+ Lo

GB Unit and LC-Display

Blood Pressure Monitor

BU 540 connect

Instruction Manual

Please read carefully!

Intended use

• This fully automatic electronic blood pressure

monitor is intended for measuring the blood

pressure at home. It is a non-invasive blood pressure

measurement system to measure the diastolic and

systolic blood pressure and pulse of an adult using

a noninvasive technique by means of a cu󰀨, which

needs to be tted on the upper arm. The useable cu󰀨

circumference is 22 to 42 cm.

• It is intended for adult indoor use only.

Contraindications

• The device is not suitable for measuring the blood

pressure of children. Ask your doctor before using it

on older children.

• The device is not suitable for use on pregnant

women and patients with implanted, electrocical

devices (e.g. pacemaker or debrillator).

Explanation of symbols

Scope of supply

Please check rst of all that the unit is complete.

The following parts are included as standard:

• 1 medisana blood pressure monitor BU 540 connect

• 1 cu󰀨 with air tube • 4 batteries (type AAA, LR03) 1.5 V

• 1 instruction manual and EMV leaet

Please contact your supplier if you notice any transport damage on unpacking

the unit.

The service centre address is shown on the attached leaet.

GB Safety Instructions

Read the instruction manual carefully before using this

device, especially the safety instructions, and keep the

instruction manual for future use. Should you give this

device to another person, it is vital that you also pass on

these instructions for use.

Please contact the service centre if you can’t solve the problem.

Do not disassemble the unit by yourself.

Cleaning and maintenance

Remove the batteries before cleaning the unit. Clean the unit using a soft cloth

lightly moistened with a mild soapy solution. Never use abrasive cleaning agents,

alcohol, naphta, thinner or gasoline etc.. Never immerse the unit or any component

in water. Be cautious not to get any moisture in the main unit. Do not wet the cu󰀨 or

attempt to clean the cu󰀨 with water. Using a dry cloth, gently wipe away any excess

moisture that may remain on the cu󰀨. Lay the cu󰀨 at in an unrolled position and

allow the cu󰀨 to air dry. Do not expose the unit to direct sunlight; protect it against

dirt and moisture. Do not expose the unit to extreme hot or cold temperatures.

Keep the device in the storage case when not in use. Store the unit in a clean and

dry location.

Disposal

This product must not be disposed of together with domestic waste.

All users are obliged to hand in all electrical or electronic devices,

regardless of whether or not they contain toxic substances, at a

municipal or commercial collection point so that they can be dis-

posed of in an environmentally acceptable manner.

Remove the batteries before disposing of the device/unit. Do not

dispose of old batteries with your household waste, but at a battery collection

station at a recycling site or in a shop. Consult your local authority or your supplier

for information about disposal.

Guidelines / Standards

This blood pressure monitor meets the requirements of the EU standard for

noninvasive blood pressure monitors. It is certied in accordance with EC

Guidelines and carries the CE symbol (conformity symbol) “CE 0297”. The blood

pressure monitor corresponds to European standards EN 60601-1, EN 60601-1-

2, EN 1060-3, EN 81060-1 and EN 81060-2. The specications of EU Guideline

“93/42/EEC of the Council Directive dated 14 June 1993 concerning medical

devices” are met and likewise those of the RED 2014/53/EC. You can request

the complete Conformity Declaration from medisana GmbH, Carl-Schurz-Str.

2, 41460 Neuss, Germany, or you can also download it from the medisana

homepage (www.medisana.de).

Electromagnetic compatibility: (see attached leaet)

Technical specications

Name and description:

Model:

Display system:

Memory slots:

Measuring method:

Power supply:

Blood pressure measuring range:

Pulse measuring range:

Maximum error tolerance for static pressure

Maximum error tolerance for pulse rate

Pressure generation:

Deation:

Protection marking against particles and water

Operating conditions:

Storage conditions:

Dimensions (L x W x H):

Cu󰀨:

Weight (main unit):

Item number:

EAN number:

Acessories:

medisana Blood pressure monitor

BU 540 connect

TMB-1490-BS

Digital display

2 x 250 measurement values

Oscillometric

6 V , 4 x 1,5 V batteries AAA LR03

0 – 299 mmHg

40 – 199 beats/min.

: ± 3 mmHg

: ± 5 % of the value

Automatic with pump

Automatic

: IP21

+5 °C to +40 °C, 15 to 90 % max. relative

humidity, 700-1060 hPa atmospheric pressure

-20 °C to +60 °C, to 93 % max. relative humidity,

non-condensing

approx. 140 x 130 x 60 mm

22 - 42 cm for adults

approx. 230 g without batteries

51182

40 15588 51182 0

Spare cu󰀨

Art. No. 51299 / EAN 40 15588 51299 5

Evaluare

Mai multe despre acest manual

Înțelegem că este plăcut să aveți un manual pe hârtie pentru Medisana BU 540 Connect Tensiometru. Puteți oricând descărca manualul de pe site-ul nostru web și îl puteți imprima singur. Dacă doriți să aveți un manual original, vă recomandăm să contactați Medisana. S-ar putea să ofere un manual original. Căutați manualul dvs. Medisana BU 540 Connect Tensiometru într-o altă limbă? Alegeți limba preferată pe pagina noastră de pornire și căutați numărul de model pentru a vedea dacă îl avem disponibil.

Specificații

Toate manualele pentru Medisana Tensiometre
Mai multe manuale pentru Tensiometre

Întrebări frecvente despre Medisana BU 540 Connect Tensiometru

Echipa noastră de asistență caută informații utile despre produs și răspunde la întrebările frecvente. Dacă descoperiți o inexactitate în întrebările frecvente, vă rugăm să ne anunțați utilizând formularul de contact.

Produse asemanatoare

Manual

Medisana BU 565 Tensiometru

Manual

Medisana BPW 300 Tensiometru

Manual

Medisana BW 333 Tensiometru

Manual

Medisana BPW 300 Connect Tensiometru

Manual

Medisana BU 584 Connect Tensiometru

Manual

Medisana BU 570 Connect Tensiometru

Manual

Medisana BU 510 Tensiometru

Manual

Medisana BU 530 Connect Tensiometru

Categorii relevante
