5.3 Selecting kilometres/miles

Selecting this setting follows immediately after entering the tyre size. Press the

RIGHT key to choose KILOMETRES (KM) or MILES (M), and conrm with the LEFT key.

The system will then switch to the age and weight setting mode.

5.4 Setting the age and weight

After the KM/MILE setting, the ones digit of the age entry will blink. Use the RIGHT

key to increase the ones digit and then conrm the value desired with the LEFT key.

The display will now switch to the tens digit. Set the desired value using the RIGHT

key and conrm the desired age with the LEFT key. The display will now change to the

ones digit of the weight setting. Set the value desired with the RIGHT key and conrm

with the LEFT key. Repeat this process up to the hundreds digit. After conrming, the

display will switch to the inspection display.

5.5 Setting the inspection interval

A ‘600 KM/M’ display will now blink. This function enables you to set the number

of kilometres/miles until the next inspection of your bicycle. By pressing the RIGHT

key you can set the number between 100 and 900 kilometres/miles. Conrm your

setting with the LEFT key. Once you have travelled the distance you have set here, a

spanner symbol will appear in the display to remind you of your bicycle inspection.

To switch o this symbol press the RIGHT key. After setting the inspection interval,

the display will switch to setting the inspection interval for the 2nd bicycle.

Repeat the steps described above. The display will now switch to setting the time.

5.6 Setting the 12/24-hour display

Press and hold down the LEFT key; the 24-hour display will blink. Use the RIGHT key

to choose the 12- or 24-hour display setting and conrm with the LEFT key.

5.7 Setting the clock

Directly after selecting the 12/24-hour display setting, you now set the time. The

hours display will blink. Pressing the RIGHT key will cause the hours display to

increase by 1. Then press the LEFT key – the minutes display will blink. Pressing the

RIGHT key will cause the minutes display to increase by 1. Then press the LEFT key

again to conrm your setting. You have now completed all your settings and the

bicycle computer is ready for use.

5.8 Bicycle computer check

To check that the bicycle computer and sensor have been correctly installed, press

the LEFT key to activate the display. Ensuring that the computer is rmly attached

to the computer mount, turn the front wheel of your bicycle and the speed will

be displayed.

5.9 Restart/Reset

To reset entered data, press both the LEFT and RIGHT key at the same time for

approx. 3 seconds. Following a restart/reset, you must enter all the settings again

(refer to sections 5.2 - 5.7).

5.10 Automatic starting/stopping of readings

You must switch on the bicycle computer each time before use (display is blank) by

pressing a key. When you start riding, all the readings will automatically start until

the bicycle comes to rest. When you continue riding, the readings will automatically

continue. The bicycle computer will switch o automatically if the bicycle is not in

use for a period longer than 5 minutes to save the battery.

6. MODES/FUNCTIONS

After starting up the bicycle computer, the display will show the speed and the

modus most recently used.

The speed is continuously calculated and updated, and ALWAYS shown in the upper

part of the display. Measuring range: 0.1 – 99.9

Press the RIGHT key to switch between the following modes:

• ODO(totaldistancetravelled):

All kilometres (miles) travelled will be stored. Maximum memory: 9,999.9

• DST(journeydistance):

Automaticallystartedwhenjourneybegins.Maximummemory:999.9

• MXS(maximumspeed):

The maximum speed attained will be stored. Maximum memory: 99.9

• AVS(averagespeed)

Maximum memory: 99.9

• TM(journeytime/journeychronometer):

Automaticallystartedwhenjourneybegins.Maximummemory:9hrs59

min 59 sec

• Temperature

Press and hold down the LEFT key in the temperature mode until C (Celsius) is

blinking. You can now change to F (Fahrenheit) using the RIGHT key. Conrm the

desired setting with the LEFT key.

• Caloriecounter-CAL

This mode displays the average calorie consumption rate.

• Fatburningrate-F

This mod displays the average fat burning rate in grams.

• SCAN(Scanfunction):

Rolling function display: keep pressing the RIGHT key until you reach the SCAN

mode. The word SCANwillappearinthedisplay.Inthismode,theDST,MXS,

AVS,TMfunctionswillautomaticallybedisplayedinapprox.4secondintervals.

• One-oscanningquickrun-through:

IfyoukeeptheRIGHTkeypresseddownforapprox.3seconds,aone-oquick

run-through will be performed against concurrent back lighting

• Backlighting

Briey pressing the LEFT key will activate the backlighting for approx. 3 seconds.

Atthesametime,thecomputerdisplaywillswitchtojourneytimemeasurement

(TM). Pressing the LEFT key again will activate the backlighting for another 3

seconds and the display will switch back to the previously set function. Briey

pressing the LEFT key twice in succession will activate the backlighting in the

respective mode for approx. 3 seconds.

• Time

Speedtrendandcomparisonarealwaysdisplayedduringthejourney:

• Speedtrend:

Shows the current speed: the wheels of the bicycle symbol will rotate forwards if

you are accelerating, or backwards if you are slowing down.

• Speedcomparison:

A “+” or “-“ sign will appear on the right of the speed display. This indicates

whether you are riding faster or slower than the previously attained average

speed(AVS).

• Displaymemory:

Thebicyclecomputerhasauniquedisplaymemoryenablingthejourney

distance(DST),averagespeed(AVS)andjourneytime(TM)toberecordedat

theendofthejourney.Attheendofthejourney(orastage),presstheLEFT

key.TheDST,AVSundTMreadingswillbesavedandmaybeviewedatalater

date (display will blink). By pressing the RIGHT key, you can then view the saved

WIRELESS

BICYCLE COMPUTER

OPERATING INSTRUCTIONS

Art. Nr.: 0523 | 20 functions

readings. To exit this mode, press the LEFT key. This display memory is suitable

for–amongstotherthings–recordingdataafteraracetoquicklysavethe

readings after crossing the nishing line.

To delete the readings refer to section 6.1

6.1Resettingtheroutedata(DST,TM,AVS)tozero

Press the RIGHT key to display (DST), and then keep the LEFT key pressed down for

approx.3seconds.The3routedatareadings(journeydistance–DST,journeytime

–TM,averagespeed-AVS)willberesettozero.

6.2Resettingthemaximumspeed(MXS)tozero

KeeppressingtheRIGHTkeyuntilthemaximumspeed(MXS)isdisplayedandthen

keeptheLEFTkeypresseddownforapprox.3seconds.Themaximumspeed(MXS)

will be reset to zero.

6.3 Resetting the calorie consumption rate (CAL) to zero

Keep pressing the RIGHT key until the calorie consumption rate (CAL) is displayed.

Then keep the LEFT key pressed down for approx. 3 seconds and the average calorie

consumption rate will be reset to zero.

6.4 Resetting the fat burning rate (F) to zero

Repeatedly press the RIGHT key until the fat burning rate (F) is displayed. Then

keep the LEFT key pressed down for 3 seconds and the average fat burning rate

will be reset to zero.

6.5 Manually setting the total distance travelled

To enter the total distance (ODO) travelled after replacing a battery or a reset, you

rst have to repeat all the setting steps from sections 5.2 Setting the tyre size to

5.7 Setting the clock.

First press the RIGHT key until the mode (ODO) is displayed. Then keep the LEFT key

pressed down for 3 seconds: the last digit of the total distance travelled will start

blinking. Press the RIGHT key to set the desired number for this digit, and conrm

by pressing the LEFT key. Then select the next digit and repeat this process until you

have entered the value desired for the total distance travelled. Then press the LEFT

key again to return to the normal (ODO) mode.

6.6 Switching between bicycle 1 and bicycle 2

By briey pressing the LEFT and RIGHT keys at the same time, you can switch the

measuring functions between bicycle 1 and bicycle 2. A dot followed by either the

number 1 or 2 will be displayed to the left of the speed display.

The total distance travelled (ODO) for bicycle 1 and 2 will be added when both

readings are displayed at the same time.

Whenyouchangethedisplay(betweenbicycle1and2),thedataforDST,TM,AVS,

MXS,CAL,andFwillbereset.

7. REPLACING THE BATTERIES

7.1 Bicycle computer

Unscrew the lid of the battery compartment (located on the underside of the bicycle

computer)usingacoin.Insertthe3Vbatterysothatthepluspole(+)isvisible.

Replace the lid and screw shut. After the batteries are inserted, all the settings must

be repeated (refer to section 5.2 Setting the tyre size).

7.2 Sensor

Insert the battery in the sensor so that the plus pole (+) is

facing the lid of the battery compartment. Then close the lid

using a coin.

8. DECLARATION OF CONFORMITY

It is hereby conrmed that the designated product conforms to the fundamental

requirementsofthefollowingEuropeanguidelines:.

2004/108/EGEMVguideline

European Parliament and Council guideline from 15.12.2004

2006/95/EG Low voltage guideline

European Parliament and Council guideline from 12.12.2006

The conformity of this product with the guidelines is established by its full compli-

ance with the harmonised and non-harmonised standards.

9. DESCRIPTION OF ERRORS

In the event of an error occurring, please check the following points rst, before you

make any complaint about the bicycle computer.

Speed not displayed

• Checkforcorrectmagnet/sensoralignment

• Checkbatteries

Incorrect speed reading, or speed is displayed when not in motion, or maximum

speed display is too high

• Checkthatyouhavetherightsettingforthetyresize

• Checkthatyouhavetherightkm/milessetting

• Checkthatmagnetandsensorarecorrectlypositioned

• ItispossiblethatunknownatmosphericorRFdisturbances,atmosphericor

radio interferences, high-voltage power lines, railway lines etc. may also

cause an incorrect speed display.

No display (blacked out)

Too high temperature, or display is exposed to direct sunlight. Display will return to

normal when cooled o.

Display shows erratic numbers

Remove bicycle computer battery and reinsert.

No display

• Checkthebatteries

• Checkthatthebatteriesareinsertedtherightwayround(+/-).

10.WARRANTYPROVISIONS

Bicycle computer article no.: 0523

This bicycle computer is provided with a 2-year warranty. The warranty period starts

from the date of purchase (purchase receipt, proof of purchase). During the warranty

period, address any complaints you may have to your dealer or the service address

provided below. During this period we will correct free of charge all faults caused by

material defects or malfunctioning.

Batteries, defects caused by improper handling, a fall, impact and the like are

excluded from the warranty. Please note that the warranty period is not aected by

any repair or replacement. The 2-year warranty period starting from the purchase

date shall remain in eect.

After the warranty period has expired, you will still be able to send the defective

bicycle computer to the service address provided below to be repaired. Any repairs

causedafterthewarrantyperiodhasexpiredare,however,subjecttocharge.After

prior telephone contact, please send your properly packaged bicycle computer (with

your purchase receipt) with sucient postage to the following address:

Prophete GmbH u. Co. KG

Lindenstrasse 50

D-33378 Rheda-Wiedenbrück

Phone: +49 (0) 5242 4108-59

Fax: +49 (0) 5242 4108-73

Email address: [email protected]

Website: www.prophete.de

0523_layout_en.indd 1 22.08.2011 19:14:44

Evaluare

Mai multe despre acest manual

Înțelegem că este plăcut să aveți un manual pe hârtie pentru Prophete 0523 Ciclocomputer. Puteți oricând descărca manualul de pe site-ul nostru web și îl puteți imprima singur. Dacă doriți să aveți un manual original, vă recomandăm să contactați Prophete. S-ar putea să ofere un manual original. Căutați manualul dvs. Prophete 0523 Ciclocomputer într-o altă limbă? Alegeți limba preferată pe pagina noastră de pornire și căutați numărul de model pentru a vedea dacă îl avem disponibil.

Specificații

Toate manualele pentru Prophete Ciclocomputere
Mai multe manuale pentru Ciclocomputere

Întrebări frecvente despre Prophete 0523 Ciclocomputer

Echipa noastră de asistență caută informații utile despre produs și răspunde la întrebările frecvente. Dacă descoperiți o inexactitate în întrebările frecvente, vă rugăm să ne anunțați utilizând formularul de contact.

Produse asemanatoare

Manual

Prophete 0511 Ciclocomputer

Manual

Prophete 0512 Ciclocomputer

Manual

Prophete 0531 Ciclocomputer

Manual

Prophete 0528 Ciclocomputer

Manual

Prophete 7038 Ciclocomputer

Manual

Prophete 0526 Ciclocomputer

Manual

Prophete 0516 Ciclocomputer

Manual

Sigma BC 12.12 STS Ciclocomputer

Categorii relevante
