installation rules. •The product features a special power

cable; if the cable is damaged, contact the Service Centre for

a replacement.

● Attention! Before reconnecting the circuit to the mains

power supply and making sure that it is working correctly, al-

ways check that the power cable is correctly installed.

Please note! Do not use with a programmer, timer, separate

remote control or any other device that activates automatic-

ally.

RECOMMENDATIONS FOR USE

Recommendations for correct use in order to reduce the im-

pact on the environment: When cooking begins, the device

should be turned on at minimum speed, and left on for a few

minutes even after cooking is complete. Increase the speed

only if there is a large quantity of fumes and steam, using the

Booster function only in extreme cases. To keep the odour

reduction system running efficiently, replace the carbon filter/

s when necessary. To ensure the high performance of the

grease filter, clean it when necessary. To improve efficiency

and minimise noise, use the maximum duct diameter indic-

ated in this manual.

END-OF-LIFE DISPOSAL

This device is marked in compliance with the

European Directive 2012/19/EC - UK SI 2013

No.3113, Waste Electrical and Electronic Equip-

ment (WEEE). Make sure that this product is dis-

posed of correctly. The user helps prevent poten-

tial negative consequences for the environment

and for health.

The symbol on the product or accompanying documentation

indicates that this product should not be treated as

household waste but should be handed over at a suitable

collection point for the recycling of electrical and electronic

equipment. Dispose of it in accordance with local regulations

for waste disposal. For further information about the

treatment, recovery and recycling of this product, please

contact your local authority, the collection service for

household waste or the shop from where the product was

purchased.

REGULATIONS

Equipment designed, tested and manufactured in compliance

with safety regulations: EN/IEC 60335-1; EN/IEC 60335-2-

31, EN/IEC 62233. Performance: EN/IEC 61591; ISO

5167-1; ISO 5167-3; ISO 5168; EN/IEC 60704-1; EN/IEC

60704-2-13;EN/IEC 60704-3; ISO 3741; EN 50564; IEC

62301. EMC: EN 55014-1; CISPR 14-1; EN 55014-2; CISPR

14-2; EN/IEC 61000-3-2; EN/IEC 61000-3-3.

USE

The extraction system can be used in the duct-out version

with external evacuation, or in the recirculating version with

filtering and internal recirculation.

● Duct-Out Version:

Vapours are evacuated outside through an exhaust pipe at-

tached to the connecting flange.

CAUTION! If the product features one or more carbon fil-

ters, they must be removed.

Connect the product to wall-mounted exhaust pipes and

holes with a diameter equivalent to the air outlet (connect-

ing flange).

The use of pipes and outlet holes in the wall with a smaller

diameter will reduce the extraction performance and

drastically increase the noise level.

All responsibility in this regard is therefore denied.

• Use a ducting pipe with the shortest length necessary.

• Use a ducting pipe with the least number of bends pos-

sible (maximum bend angle: 90°).

• Avoid drastic changes in the ducting pipe diameter.

● Recirculating Version:

The suctioned air will be degreased and deodorised before

it is sent back into the room. To use the product in this ver-

sion, it is necessary to install an additional activated carbon

filter system.

ASSEMBLY BEFORE INSTALLATION

• Check that the product is the right size for the installation

area.

• Remove the activated carbon filter(s) if supplied (see also

relevant paragraph).

• It(they) must be reinstalled if the product is used in the fil-

ter version.

• If there are panels and/or walls and/or wall units on the

sides, make sure that there is enough space to install the

product and that it is always possible to access the control

panel easily.

• The product is equipped with fixing plugs suitable for most

walls/ceilings. However, it is necessary to consult a quali-

fied technician to make sure that the materials are suitable

for the type of wall/ceiling. The wall/ceiling must be strong

enough to support the weight of the hood.

Attention! removing the protective film might leave some

marks. In this case, the marks can be removed with warm

water.

OPERATION

T1 Motor ON/OFF

Press the button to start the hood at speed 1.

Press the button during operation to switch the hood OFF.

T2 Increase speed

Press the button to switch the hood from OFF to speed 1.

Press the button (with hood ON) to increase the motor

8
