PROGRAMMES

For choosing the appropriate programme for your kind of

laundry, always respect the instructions on the care labels

of the laundry. The value given in the tub symbol is the

maximum temperature possible for washing the garment.

Mixed

For washing lightly to normally soiled resilient garments in cotton, linen,

synthetic fibres and mixed fibres.

Eco 40-60

For washing normally soiled cotton garments declared to be washable

at 40 °C or 60 °C, together in the same cycle. This is the standard cotton

programme and the most efficient in terms of water and energy

consumption.

! The cycle runs only at 40°C as per regulation.

20 °C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Colours

White and pastel shaded garments made of delicate fabrics.

Gentle wash programme to avoid graying or yellowing of your laundry.

Use heavy duty detergent, if necessary also stain removers or bleaches on

oxygen basis. Do not use liquid detergent.

Wool

All wool garments can be washed using programme ‚ “Wool“ even

those carrying the “hand-wash only“ label. For best results, use special

detergents and do not exceed max kg declaration of laundry.

Spin

Spins the load then empties the water. For robust laundry.

Rinse + Spin

Separate rinse and intensive spin programme. For robust

laundry.

Delicates

For washing particularly delicate garments. Preferably turn garments

inside out before washing.

Hygiene

This program removes 99 % of bacteria while washing normally to heavily

soiled bed linen, table linen and underwear, towels, shirts etc. made of

cotton and linen.

Synthetics

For washing soiled garments made from synthetic fibres (such as

polyester, polyacrylic, viscose, etc.) or cotton/synthetic blends.

Rapid 30’

Shortly worn clothing made of cotton, polyester, polyamide and blends

with cotton. Brief programme to refresh your laundry.

Cotton

Normally to heavily soiled and robust cottons.

FIRST TIME USE

To remove any manufacturing debris select the “Cotton“ programme

at a temperature of 95°C. Pour a small quantity of detergent powder into

the main wash compartment of the detergent dispenser (maximum

1/3 of the quantity the detergent manufacturer recommends for lightly

soiled laundry). Start the programme without adding any laundry.

DAILY USE

Prepare your laundry according to the recommendations in the “HINTS

AND TIPS“ section. Load the laundry, close the drum door and check that

it is closed properly. Pour in the detergent and any additives. Observe the

dosing recommendations on the detergent pack. Close the lid. Turn the

programme selector to the desired programme and select any option if

needed. The display shows the duration of the selected programme (in

hours and minutes), and the indicator for the “Start/Pause“ button

flashes. The spin speed can be changed by pressing the “Spin“ button.

The indicator of the predefined spin speed lights up. Open the tap and

press the “Start/Pause“ button to start the wash cycle. The “Start/

Pause“ indicator will lights up and the door will be locked. Due to

variations in load and temperature of inlet water, the remaining time is

newly calculated in certain programme phases. If this is the case, an

animation appears on the time display.

PAUSE OR CHANGE A RUNNING PROGRAMME

To pause the wash cycle, press the “Start/Pause“ button, the indicator

light blinks. Select any new programme, options or spin speed if you wish

to change those settings. Press the “Start/Pause“ button again to start

the wash cycle from the point at which it was interrupted. Do not add

detergent for this programme.

LID OPEN INDICATOR

Before starting and after the end of a programme, the “Lid open“

indicator lights to show that the lid can be opened. As long as a wash

programme is running, the lid remains locked and must on no account

be forced open. In case you have an urgent need to open it during a

running programme, for example to add more laundry, or to remove

laundry which was loaded by mistake, press the “Start/Pause“

button. If the temperature is not too high, the “Lid open“ indicator

light turns on. It may last a while until you can open the lid. Press “Start/

Pause“ to proceed with the programme again.

PROGRAMME END

The “Lid open“ indicator lights up and the display shows .Turn

the programme selector to the “O“ position and close the water tap.

Open the lid and drum and unload the machine. Leave the Lid open

for some time to allow the interior of the machine to dry. After about a

quarter of an hour, the washing machine will switch off completely to

save energy.

To cancel a running programme before the end of cycle, press the

“Reset/Drain“ button for at least 3 seconds. The water is drained out.

It may last a while until you can open the lid.

OPTIONS

! When the combination of programme and additional option(s) is not

possible, the indication lights switch o automatically.

! Unsuitable combinations of options are deselected automatically.

Colours 15°

Saves energy used for water heating while maintaining a good wash

result. Supports colour maintenance when washing coloured laundry.

Recommendable for lightly soiled laundry without stains. Make sure that

your detergent is suitable for cold wash temperatures.

Fresh Care

Select this option if you cannot unload the laundry soon after

programme end, or if you tend to forget the laundry in your washing

machine. It will help to keep your laundry fresh. The washing machine

will start to tumble the laundry periodically after programme end. The

light of the “Fresh Care“ button will blink while this function is active,

and the display will show an animation. The periodic tumbling will last up

to approximately 6 hours after the end of your wash programme, and you

can stop it at any time by pressing the “Fresh Care“ button. It will last

a while until you can open the door. After the “Fresh Care“ period has

run out, the display indicates .

Start delay

To set the selected programme to start at a later time, press the “Start

delay“ button to set the desired delay time. The lamp for the

“Start delay“ option button lights up, and it goes off when the

programme starts. Once having pressed the “Start/Pause“ button,

the countdown of the time delay begins. Number of hours pre-selected

can be reduced by pressing the “Start delay“ button again. Do not

use liquid detergent when activating this option. To cancel the “Start

delay“ turn the programme selector to another position.

Rapid

Enables quicker washing by shortening the programme duration.

Recommendable for small loads or only lightly soiled laundry.

Prewash

Only for heavily soiled loads (for example sand, granular dirt). Increases

the cycle time by approximately 15 min. Do not use liquid detergent for

the main wash when activating the Prewash option.

Energy saver

With a lower temperature and slightly modified washing duration, the

optimum combination of excellent washing results

and even lower energy consumption is achieved.

Intensive rinse

Helps to avoid detergent residues in the laundry by extending the rinse

phase. Particularly suitable for washing baby laundry, for people suffering

from allergies and for areas with soft water.

Spin

Every programme has a predefined spin speed. If you want to change the

spin speed, press the “Spin“ button. If spin speed “0“ is selected, the

final spinning is cancelled but intermediate spin peaks remain during the

rinse. The water is drained out only.
