Operating Instructions

9

WOOD’S, THE WORLD’S LEADING

DEHUMIDIFIERS

Wood’s dehumidifier products have

been known as market leaders for many

years. Their dehumidifiers are suitable

for use in the most demanding climates,

where dehumidifying capacity is good

even at lower temperatures and humidity

levels. They are used with good results

in premises that become damp such as

large open spaces, storage rooms and

buildings.

The amount of humidity that the

dehumidifier removes depends on

temperature, humidity level and

placement. External weather conditions

may also affect the performance of

the dehumidifier. In cold weather the

absolute humidity decreases and thus

the extraction of humidity from the air by

the dehumidifier is reduced. (The relative

humidity might still be on a high level.)

The dehumidifier is suitable for use in the

temperature range +2˚C to +35˚C.

Wood’s dehumidifiers are safe in

operation and intended for continuous

use over many years.

EXCESSIVE AIR HUMIDITY  A DANGER

Condensation occurs when water vapour

in the air comes into contact with a cold

surface such as cold window or wall.

When water vapour is cooled down,

condensation occurs, and water-drops are

formed. In high air humidity, the air may

get musty and mould might get formed,

causing damage to a house and its

furnishings. This environment may even

cause illness for the residents. Mites and

spiders also thrive in a damp environment.

A dehumidifier with high performance

creates a good, healthy humidity level. For

greatest efficiency the doors and windows

of rooms that are being dehumidified

should be kept closed. Removes odours,

dries wood and removes moisture from

sportsware outdoors equipment.

A dehumidifier may be used for buildings

and in large and open spaces, If the

humidifier is kept in colder environments,

you should study the Hints at the end of

the manual.

PLACEMENT OF DEHUMIDIFIER

Wood’s dehumidifiers are easy to move

around, all you need to have is a power

source for 220/240V, but bear in mind the

following:

- The dehumidifier should not be placed

near radiators or other heat sources or

exposed to direct sunlight, as it will reduce

performance.

- It is beneficial to use a radiator or heating

fan to keep the temperature above +2˚C.

- The dehumidifier should stand at least

25cm from a wall or other obstruction, for

maximum air flow.

- Ideal is to put it in the center

of the room / area.

NOTE: When placed in a shower or

bathing area, the dehumidifier should

be fixed in place. It is compulsory to

check and respect your local bathroom

electrical regulations before use.

USING THE DEHUMIDIFIER

The dehumidifier should be transported

according to the instructions. In the event

of improper positioning during transport,

oil may flow out of the compressor and

into the closed pipe system. In such a

case, let the dehumidifier stand for a

4 hours before being used. It is very

important that the oil runs back into the

compressor, otherwise the dehumidifier

may be seriously damaged.

1. Check that the water reservoir is correctly

placed and the float moves freely in the

reservoir. See the section on the Float.

2. Connect the dehumidifier to an grounded

power source.

3. Select fan speed.

4. Set the desired humidity level by means of

the humidity control. See the section on the

humidity control.

NOTE: When the dehumidifier

is turned off, it will take 5 minutes

before the dehumidifier is restarted,

the built-in automatic functions are

deactivated, during this period.

THE FLOAT

The float consists of a white plastic

cylinder which hangs on two arms.

The float rests on the surface, so it is

lifted when the water level rises. When

the float reaches a certain height, the

dehumidifier responds to this and shuts

down automatically to prevent flooding

of the tank.

When you have emptied the water

reservoir and are to replace it in the

dehumidifier follow these steps:

1. Push the water reservoir in until it

touches the float.

2. Raise the forward edge of the water

reservoir from below so that the whole

water reservoir is slightly slanted.

3. Push the water reservoir home. The

float should now be in the reservoir

instead of being stuck behind it.

NOTE: It is important that the float

moves freely, since its purpose is to

respond to the water level and ensure

that the dehumidifier is turned off when

it is high. A wrongly placed float may

allow the water reservoir to flood.
