Operating Instructions

10

DRAINAGE OF WATER

The dehumidifier is fitted with a hose

connection. By attaching a hose to the

dehumidifier the condensed water can be

drained directly away.

Using the hose:

1. Disconnect the dehumidifier from the

power source and remove the water

reservoir to give access to the drip tray.

2. Attach the hose coupling to the thread on

the dehumidifier and lead the hose to a

drainage outlet. Check that the hose is not

above the level of the drip tray.

3. Connect the dehumidifier to the power

source.

Without hose, direct to a drain outlet:

1. Disconnect the dehumidifier from the

power source and remove the water

reservoir.

2. Place the dehumidifier directly over the

drain so that the dehumidified water can

drip through the hole at the base of the

dehumidifier and into the drain.

3. Connect the dehumidifier to the power

source.

HUMIDITY CONTROL

Wood’s dehumidifier is fitted with a built

in humidity control, which is set to the

desired level of humidity. The control

registers the current level of humidity and

ensures that the dehumidifier is turned on

and off automatically.

How to set the humidity control:

1. Set the humidity control knob to the

maximum position.

2. Set the fan to position II .

3. When the desired level of humidity is

reached, the hygrostat knob is turned

counterclockwise until the dehumidifier is

turned off.

NOTE: The ambient relative

humidity is most simply measured

with a Wood’s hygrometer, and the most

suitable range is between 50% and 60%.

SHUTTING OFF AUTOMATICALLY

When the water reservoir is full, the

dehumidifier is shut off automatically.

The indicator light at the front of the

dehumidifier will switch to red to show

that the water reservoir should be

emptied.

1. Disconnect the dehumidifier from the

power source.

2. Empty the water reservoir.

3. Put the empty water reservoir back and

check that the float moves freely. See the

section on the Float.

4. Connect the dehumidifier to the power

source.

THE AIR FILTER

The air filter at the rear of the

dehumidifier ensures that the cooling

coils are kept free from dust. It is

important that the filter is kept clean

so that air can flow freely through the

dehumidifier.

Your dehumidifier is equipped with

a washable-filter that enhances the

capacity of the dehumidifier and cleanses

the air further. Please refer to the

separate filter leaflet for installation and

maintenance instructions.

AUTOMATIC DEFROSTING

Wood’s dehumidifiers are fitted with

a control unit which ensures that the

cooling coils are defrosted automatically

when needed. The control shuts down

the compressor, which causes the cooling

of the coils to stop. The fan continues

to draw the air at room temperature

through the dehumidifier and thus melts

the ice, and the water runs down into

the reservoir. This defrosting system

means that the dehumidifier works at

temperatures as low as +2˚C.

FAN

The fan ensures that air flows through the

dehumidifier. Moist air is sucked in from

the rear and goes via the cooling coil and

the vaporizer to come out dry and warm

at the front of the dehumidifier. Wood’s

dehumidifiers are fitted with two fan

speeds.

• Position II – gives a high air flow with

maximum dehumidifying of air.

• Position I – gives a lower air flow

which causes quieter operation and

somewhat lower dehumidifying

capacity.

ACCESSORIES

The dehumidifiers in WCD-series (WCD2,

WCD3 and WCD4) can be equipped with

an external water pump to drain the

condensate water. This is an accessory

and it is sold separately.

The dehumidifiers in WCD-series (WCD2,

WCD3 and WCD4) can be equipped with

a F8 filter which is efficient to capture

silica dust. When using a F8 filter it

should be replaced regularly (when full)

and not cleaned. You can contact your

reseller for further usage instructions and

replacement cycles. This is an accessory

and it is sold separately.
